CURTIS PART NUMBERS, CURTIS 5HP PARTS, CURTIS 7.5HP PART LIST, CURTIS E57 PARTS, CURTIS E57 PUMP






CURTIS E57 COMPRESSOR PUMP
5HP-7.5HP






























ITEM DESCRIPTION
NUMBER ITEM NUMBER
UNLOADER KIT  1ST. FSK-E57UK-1
UNLOADER KIT 2ND. FSK-E57UK-2
GASKET KIT FSK-E57GK
VALVE / GASKET KIT FSK-E57VK
LOWER END KIT FSK-E57LERK
RING KIT FSK-E57RK
SOME ITEMS CAN BE FOUND IN MULTIPLE KITS
ITEM DESCRIPTION QTY PART NUMBER
AIR STRAINER
1 Air Strainer Assembly 1 2601540262
2 Air Strainer Element 1 2601540300
3 Air Strainer Cover Gasket 1 2601540330
UNLOADER 1ST.
4 Unloader Copper Tee 1
5 Unloader Push Cover Bolt; M6 x L25, Gr 8.8 (1st) 2
6 Unloader Push Cover Spring Washer; M6 (1st) 7
7 Unloader Push Cover (1st) 1
8 Unolader Push Cover Gasket (1st) 1
9 Unloader Assembly (1st) 1
10 Unloader Piston (1st) 1
11 Viton O-Ring Unloader (1st) 1
12 Unloader Spring (1st) 1
13 Unloader Cylinder (1st) 1
14 Unloading Fork (1st) 1
15 Unloader Bolt; M6 x L16 Gr 8.8 (1st) 1
16 Unloader Gasket (1st) 1
UNLOADER 2ND
17 Unloading Elbow 1
18 Unloader Assembly (2nd) 1
19 Unloader Push Cover (2nd) 1
20 Viton O-Ring Unloader (2nd) 1
21 Unloader Piston (2nd) 1
22 Unloader Spring (2nd) 1
23 Unloader Copper Washer (2nd) 1
24 Unloader Body (2nd) 1
CYLINDER HEAD
25 Cylinder Head Bolt; M10 x L85, Gr 8.8 6 2102010337
26 Cylinder Head Spring Washer; M10 7 2102040140
27 Cylinder Head 1 2601022860
28 Cylinder Head - Valve Seat Gasket 1
VALVE ASSEMBLY
29 Valve Plate Assembly 1
30 Valve Seat Bolt; M5 x L12, Gr 8.8 3
31 Valve Seat Bolt Spring Washer; M5 3
32 Valve Seat (Upper) 1
33 Valve Seat Gasket 1
34 Valve Plate (1st) 4
35 Valve Plate Spring (1st) 4
36 Valve Plate (2nd) 2
37 Valve Plate Spring (2nd) 2
38 Valve Seat (Bottom) 1
39 Cylinder-Valve Seat Gasket 1
CYLINDER, PISTON & RING
40 Compression Ring (1st) 2
41 Oil Control Ring (1st) 2
42 Piston (1st) 1 2601023361
43 Piston Snap Ring 4 2601023370
44 Piston Pin (1st) 1 2601023420
45 Compression Ring (2nd) 3
46 Oil Control Ring (2nd) 1
47 Piston Pin (2nd) 1 2601023570
48 Piston (2nd) 1 2601023500
49 Cylinder 1 2601023100
50 Cylinder Bolt; M10 x L30, Gr 8.8 11 2102010276
51 Cylinder Copper Washer; M10 13
52 Cylinder Crankcase Gasket 1
CONNECTING ROD
53 Connecting Rod Assembly (1st) 1
54 Piston Pin Bushing (1st)  (Supplied with Item 53 only) 1 2601023391
55 Connecting Rod Crank Pin Metal (1st) 4
56 Connecting Rod Assembly (2nd) 1 2601023600
57 Piston Pin Needle Bearing (2nd)  (Supplied with Item 56 only) 1 2110090039
CRANKCASE & CRANKSHAFT
58 Rear Bearing Cover Bolt; M8 x L30, Gr 8.8 3 2102011146
59 Rear Bearing Cover 1 2601023281
60 Rear Bearing Cover Gasket 1
61 Front & Rear Bearing 2
62 Screw in Oil Level Glass 1 2601037952
63 Oil Level Glass Gasket 1 2111010210
64 Crankcase Oil Plug (Special non-standard) 1 2102020041
65 Crankcase 1 2601023200
66 Oil Fill Cap 1 2601024910
67 O-ring (Oil Fill Cap) 1 2111010013
68 Crankshaft 1 2601023150
69 V-Pulley Pin 1 2601024660
70 Front Bearing Cover Gasket 1
71 Front Bearing Cover 1 2601023220
72 Breather Assembly 1 2601026681
73 Front Oil Seal 1
74 Compressor Pulley 1 2601230941
75 Compressor Pulley Thrust Washer 1 2601231780
INTER-COOLER
76 Inter-Cooler Bolt (Upper) 3 2102011161
77 Inter-Cooler Body Gasket (Upper) 1
78 Inter-Cooler Body 1 2601510140
79 Inter-Cooler Body Gasket (Bottom) 1
80 Inter-Cooler Bottom Cover 1 2601510161
81 Inter-Cooler Bolt (Bottom) 4 2102010123
82 Discharge Elbow 1 2601490971
83 Discharge Elbow Nut 1 2688360290







AIR COMPRESSOR SERVICE

AIR COMPRESSOR PUMP REPAIR

AIR COMPRESSOR MOTOR REPAIR

AIR COMPRESSOR DRYER

AIR COMPRESSOR DRYER SERVICE


214-428-2868

AIR COMPRESSOR PARTS

AIR COMPRESSOR OIL







WWW.HKAIRCOMPRESSORS.COM
AIR COMPRESSOR SERVICE








WWW.HKAIRCOMPRESSORS.COM
AIR COMPRESSOR SERVICE










WWW.HKAIRCOMPRESSORS.COM
AIR COMPRESSOR SERVICE









WWW.HKAIRCOMPRESSORS.COM
AIR COMPRESSOR SERVICE





214-428-2868

AIR COMPRESSOR PARTS

AIR COMPRESSOR OIL






AIR COMPRESSOR SERVICE










AIR COMPRESSOR SERVICE











AIR COMPRESSOR SERVICE









AIR COMPRESSOR SERVICE





214-428-2868

AIR COMPRESSOR PARTS

AIR COMPRESSOR OIL






AIR COMPRESSOR SERVICE










AIR COMPRESSOR SERVICE









AIR COMPRESSOR SERVICE





AIR COMPRESSOR SERVICE

AIR COMPRESSOR PUMP REPAIR

AIR COMPRESSOR MOTOR REPAIR

AIR COMPRESSOR DRYER

AIR COMPRESSOR DRYER SERVICE


214-428-2868

AIR COMPRESSOR PARTS

AIR COMPRESSOR OIL




CALL FOR PRICES:


TYPICALLY IN STOCK ITEMS:


CURTIS CA SERIES FCA05E50H8S-A9L1XX CA5 HORZ 80G 3/60/200V 175PSI STD
CURTIS CA SERIES FCA05E50V8M-A2L1XX CA5 VERT 80G 1/60/230V 175PSI SPEC
CURTIS CA SERIES FCA05E57H8S-A9L1XX CA5+ HORZ 80G 3/60/200V 175PSI STD
CURTIS CA SERIES FCA05E57V8S-A2L1XX CA5+ VERT 80G 1/60/230V 175PSI STD
CURTIS CA SERIES FCA05E57V8S-A4L1XX CA5+ VERT 80G 3/60/460V 175PSI STD
CURTIS CA SERIES FCA05E57V8S-D2L1XX CA5+ VERT 80G 1/60/230V 175PSI DUAL
CURTIS CA SERIES FCA05E57V8U-A4L1XX CA5+ VERT 80G 3/60/460V 175PSI ULTRA
CURTIS CA SERIES FCA05E57V8U-A9L1EI CA5+ VERT 80G 3/60/200V 175PSI ULTRA EI
CURTIS CA SERIES FCA05E57V8X-A3L1XX CA5+ VERT 80G 3/60/230V 175PSI SPEC
CURTIS CA SERIES FCA07E57H3X-A3L1XX CA7.5 HORZ 30G 3/60/230V 175PSI SPEC
CURTIS CA SERIES FCA07E57H8S-A2L1XX CA7.5 HORZ 80G 1/60/230V 175PSI STD
CURTIS CA SERIES FCA07E57H8S-A4L1XX CA7.5 HORZ 80G 3/60/460V 175PSI STD
CURTIS CA SERIES FCA07E57V8A-A4L1S1 CA7.5 VERT 80G 3/60/460V 175PSI SPEC
CURTIS CA SERIES FCA07E57V8S-A3L1XX CA7.5 VERT 80G 3/60/230V 175PSI STD
CURTIS CA SERIES FCA07E57V8U-A3L1XX CA7.5 VERT 80G 3/60/230V 175PSI ULTRA
CURTIS CA SERIES FCA07E57V8U-A9L1XX CA7.5 VERT 80G 3/60/200V 175PSI ULTRA
CURTIS CA SERIES FCA07E57V8X-A2L1XX CA7.5 VERT 80G 1/60/230V 175PSI SPEC
CURTIS CA SERIES FCA07E57V8X-A3L1XX CA7.5 VERT 80G 3/60/230V SPEC
CURTIS CA SERIES FCA10E71D1U-A4L1XX CA10 DUPL 120G 3/60/460V 175 PSI ULTRA
CURTIS CA SERIES FCA10E71H1S-A3L1XX CA10 HORZ 120G 3/60/230V 175PSI STD
CURTIS CA SERIES FCAHEE57H3X-AXL1XX CA13 HORZ 30G 175PSI SPEC
CURTIS CT SERIES FCT02C36H4X-A1J1XX CTS2 HORZ 4G 1/60/115V 125PSI STD
CURTIS CT SERIES FCT02C48H2X-A1X1XX CTS2 HORZ 20G 1/60/115V 135PSI STD
CURTIS CT SERIES FCT02C48H9X-A1X1XX CTS2 HORZ 9G 1/60/115V 135PSI STD
CURTIS CT SERIES FCT02C48V3X-A1X1XX CTS2 VERT 30G 1/60/115V 135PSI STD
CURTIS CT SERIES FCT03C47V6X-A2X1XX CTS3 VERT 60G 1/60/230V 135PSI STD
CURTIS CT SERIES FCT05C30V6X-A2X1XX CTS5 VERT 60G 1/60/230V 135PSI STD
CURTIS CT SERIES FCT05C55V6X-A2L1XX CT5 VERT 60G 1/60/230V 175PSI STD
CURTIS CT SERIES FCT05C55V8X-A2L1H1 CT5 VERT 80G 1/60/230V 175PSI SPEC
CURTIS CT SERIES FCT07C75H8S-A2L1XX CT7.5 HORZ 80G 1/60/230V 175PSI STD
CURTIS CT SERIES FCT07C75V8S-A2L1XX CT7.5 VERT 80G 1/60/230V 175PSI STD
CURTIS CT SERIES FCT07C75V8S-A4L1XX CT7.5 VERT 80G 3/60/460V 175PSI STD
CURTIS CT SERIES FCT10C75H1S-A3L1XX CT10 HORZ 120G 3/60/230V 175PSI STD
CURTIS CT SERIES FCT10C75H1S-A4L1XX CT10 HORZ 120G 3/60/460V 175PSI STD
CURTIS CT SERIES FCT10C75H8S-A4L1XX CT10 HORZ 80G 3/60/460V 175PSI STD
CURTIS CT SERIES FCTHEC47H9X-AXX1XX CTS5 HORZ 9G 135PSI STD
CURTIS CT SERIES FCTKDC75H3X-AXL1XX CT14 HORZ 30G 175PSI SPEC
CURTIS CT SERIES FCTKDC75H6X-AXL1XX CT14 HORZ 60G 175PSI SPEC





E57 AIR FILTERS:
CALL FOR PRICES AND AVAILABILITY.

AIR COMPRESSOR FILTER









WWW.HKAIRCOMPRESSORS.COM
214-428-2868



AIR COMPRESSOR OIL





214-428-2868

AIR COMPRESSOR PARTS

AIR COMPRESSOR OIL














CA SIMPLEX MACHINE


Capacity and power: ISO-1217(1996 annex #C)
Normal working pressure - psi 175
Capacity at normal working press - cfm 18.5
Basic Pump
Model E57
Stage 2
Lubrication type Splash Lubrication
Valve type Channel Valve - Stainless Steel
RPM (min - max) - rpm 800 - 1050
Outfit RPM 901
BHP - HP 5.489
Bore (LP/HP) - inch 3.94” - 2.17”
Stroke - inch 3.39”
Inlet size Rc1 BSPT
Discharge size 7/8 OD
Sheave OD 16.53”
Sheave PD 16.28”
Number of belts 2
Belt section A
Low oil sight glass Sight Glass
Oil quantity 4 Pints
Unloaders and Method Pressure Switch Unloader standard, Suction Head Option
Noise level - dB(A) 84
Motor 1-230V 3-200V 3-230V 3-460 3-575V
Enclosure IP23 IP23 IP23 IP23 IP23
Insulation Class F F F F F
Efficiency - % 82.5 87.5 89.5 89.5 89.5
Nominal rated power - HP 5 5 5 5 5
Speed of rotation - rpm 1725 1750 1750 1750 1750
FLA 23.0 16.4 13.2 6.6 5.3
Service factor 1.15 1.15 1.15 1.15 1.15
Locked rotor current - A 129 109 95 47 38
Power Factor 87 74 80 80 80
Installation condition
Allowed ambient temperature min - max - °F 32-104
Compressor dimensions
Air Receiver Type Vertical Vertical UP Horizontal Horizontal UP
Air receiver size (Gal) 80 80 80 80
Compressor outlet 1/2” NPT 1/2” NPT 1/2” NPT 1/2” NPT
Length - inch 36 39 69 67
Width - inch 25 32 24 29
Height - inch 74 77 47 51
Weight - Lbs. 510 575 510 575
Air Cooled Aftercooler (Option)
Availability Yes
Air cooled aftercooler CTD - °F 18



CA SERIES DUPLEX MACHINE



Capacity and power: ISO-1217(1996 annex #C)
Normal working pressure - psi 175
Capacity at normal working press - cfm 37
Basic Pump
Model E57
Stage 2
Lubrication type Splash Lubrication
Valve type Channel Valve - Stainless Steel
RPM (min - max) - rpm 800 - 1250
Outfit RPM 901
BHP - HP 5.49
Bore (LP/HP) - inch 3.94” - 2.17”
Stroke - inch 3.39”
Inlet size Rc1 BSPT
Discharge size 7/8 OD
Sheave OD 16.53”
Sheave PD 16.28”
Number of belts 2
Belt section A
Low oil sight glass Sight Glass
Oil quantity 4 Pints
Unloaders and Method Pressure Switch Unloader standard, Suction Head option
Noise level - dB(A) 84
Motor 1-230V 3-200V 3-230V 3-460 3-575V
Enclosure IP23 IP23 IP23 IP23 IP23
Insulation Class F F F F F
Efficiency - % 82.5 87.5 89.5 89.5 89.5
Nominal rated power - HP 5 5 5 5 5
Speed of rotation - rpm 1725 1750 1750 1750 1750
FLA 23.0 16.4 13.2 6.6 5.3
Service factor 1.15 1.15 1.15 1.15 1.15
Locked rotor current - A 129 109 95 47 38
Power Factor 87 74 80 80 80
Installation condition
Allowed ambient temperature min - max - °F 32-104
Compressor dimensions
Air Receiver Type Horizontal Horizontal UP
Air receiver size (Gal) 120 120
Compressor outlet 3/4” NPT 3/4” NPT
Length - inch 76 78
Width - inch 27 29
Height - inch 52 53
Weight - Lbs. 910 975
Air Cooled Aftercooler (Option)
Availability Yes
Air cooled aftercooler CTD - °F 18
