The Rotary Screw Air Compressor


The rotary screw air compressor produces an ongoing movement to generate power. For certain heavy-duty industrial operations, or a facility that needs to keep running their compressor 24/7 365 days a year, a piston compressor is considered insufficient. In order to get the pressure intensity needed for complex pneumatic and other high-powered tools, you will need to consider buying a rotary screw air compressor.


































THERE ARE A LOT OF AIR COMPRESSOR BRANDS IN THE WORLD BUT VERY FEW AIR COMPRESSOR SERVICE CENTERS IN DALLAS, FORT WORTH AND SURROUNDING AREAS.  IF YOU ARE LOOKING FOR INDUSTRIAL AIR COMPRESSORS FOR YOUR SHOP, FACTORY, MANUFACTURING PLANT, THEN CALL US AT: 214-428-2868

WE HAVE BEEN IN BUSINESS FOR 50 YEARS.  WE KNOW HOW TO SERVICE, MAINTAIN AND REPAIR ALMOST ALL BRANDS OF INDUSTRIAL PISTON AND ROTARY SCREW AIR COMPRESSORS.

WWW.HKAIRCOMPRESSORS.COM














In a rotary screw compressor, air is compressed with a meshing pair of rotors. As the screws move in rotation, fluids gets sucked in, compressed and ejected.





















So, how does an oil injected rotary screw compressor work?

AIR

The outside air is sucked in by the screw element (air-end) through the air inlet filter. The inlet filter makes sure that all the dust and dirt stays outside.








Load and unload control

Before the air enters the screw element, it passed the inlet valve or unloader valve. This valve opens and closes the air supply to the screw element.

When it’s open, the compressor is in ‘loaded’ condition:
When the valve is closed, is shuts off the air supply to the compressor element: the motor and screw element are turning, but the compressor is not sucking any air in and is not pumping any air to the system.











Rotary Screw Air Compressors

Marble cutting air compressors
Stone cutting air compressors
Manufacturing air compressors
Automotive air compressors
CNC air compressors
Aviation air compressors
Plasma cutting air compressors
Food processing air compressors
Recycling facilities
Cement facilities
Schools
Jails
Cabinet and framing compressors
General construction












If you need an industrial air compressor with the volume to do the job; call: 214-428-2868

Definitely look at a Rotary Screw Compressor.












































WHAT DOES THE screw compressor element DO?


When the inlet/unloader valve is open, the air enters the compressor screw element.
The screw element works like a pump and it compressed the air. During this process, oil is injected in the element. The oil is there to cool the air, as the air gets very hot during compression.















H&K SERVICES ALL TYPES OF  PISTON, ROTARY SCREW, AND CLIMATE CONTROL COMPRESSORS.  IF YOU ARE LOOKING FOR A NEW ROTARY SCREW, MOBILE GAS COMPRESSOR; OR JUST NEED SOMEONE TO REBUILD YOUR COMPRESSOR PUMP;
CALL: 214-428-2868
Rotary Screw Air Compressors




























Compressed air/oil mixture









This mixture leaves the screw element through a one-way valve. This valve makes sure that the oil cannot flow back into the compressor element through the exit pipe.










WHAT IS THE PURPOSE OF THE OIL SEPARATOR?

It's job is to basically separate the oil and the air through the separator tank. Most of the oil is separated from the compressed air by centrifugal force . The remaining oil is separated by the separator element which looks exactly like a big filter.


The air with oil flows through the separator element and separates the oil from the compressed air. The separated oil is collected at the bottom of the separator and is removed by the scavenge line. It sucks the collected oil back to the compressor element.





















WHAT IS THE MINIMUM PRESSURE VALVE?


The minimum pressure valve is a spring-loaded valve that opens at a certain pressure, about 2.5 bar. The minimum pressure valve makes sure that there is always a minimum pressure inside the compressor






The after cooler

The compressed air is still very hot, consequently the compressed air is now cooled by the after cooler before it leaves the compressor. The air temperature after the cooler is around 25 – 40 degrees Celsius.
Because of the cooling down of the air, a lot of water vapor has condensed against the inside of the after cooler. This water is carried with the compressed air towards the air outlet of the compressor.










Moisture trap

The condenstate trap (moisture trap) basically separates the water from the compressed air. The water is drained through a small hose.










Oil flow

The oil is cooled by the oil cooler. The amount of cooling is controlled by a thermostatic valve. If the oil is still cold, the oil cooler is completely by-passed. If the oil is very hot, all the oil is led through the oil cooler.











The Oil filter

Finally, the oil flows through the oil filter. The oil filters removes all the dirt and dust that has collected in the oil.
















PISTON AIR COMPRESSORS

ROTARY SCREW AIR COMPRESSORS

CLIMATE CONTROL AIR COMPRESSORS

CURTIS CLIMATE CONTROL PUMPS

CURTIS CLIMATE CONTROL REPLACEMENT PUMPS



AIL COMPRESSOR OIL

AIR COMPRESSOR FILTERS

AIR COMPRESSOR SEPARATORS

AIR COMPRESSOR BELTS AND HOSES

AIR COMPRESSOR RADIATORS

AIR COMPRESSOR DRYERS

AIR COMPRESSOR VALVES

AIR COMPRESSOR CHECK VALVES

AIR COMPRESSOR PISTONS

AIR COMPRESSOR PRESSURE SWITCHES

AIR COMPRESSOR STARTERS

AIR COMPRESSOR MOTORS

AIR COMPRESSOR SERVICE KITS




























Call: 214-428-2868











Model HP VOLT  PSI CFM Part Number
NxB30 40 230 100 196 FNB30DXX3HXXX
NxB30 40 460 FNB30DXX4HXXX
NxB30 40 230 125 173 FNB30DXX3JXXX
NxB30 40 460 FNB30DXX4JXXX
NxB30 40 230 150 163 FNB30DXX3KXXX
NxB30 40 460 FNB30DXX4KXXX
NxB30 40 230 175 149 FNB30DXX3LXXX
NxB30 40 460 FNB30DXX4LXXX
NxB37 50 230 100 234 FNB37DXX3HXXX
NxB37 50 460 FNB37DXX4HXXX
NxB37 50 230 125 203 FNB37DXX3JXXX
NxB37 50 460 FNB37DXX4JXXX
NxB37 50 230 150 193 FNB37DXX3KXXX
NxB37 50 460 FNB37DXX4KXXX
NxB37 50 230 175 180 FNB37DXX3LXXX
NxB37 50 460 FNB37DXX4LXXX
NxB30 40 230 100 196 FNB30DXD3HXXX
NxB30 40 460 FNB30DXD4HXXX
NxB30 40 230 125 173 FNB30DXD3JXXX
NxB30 40 460 FNB30DXD4JXXX
NxB30 40 230 150 163 FNB30DXD3KXXX
NxB30 40 460 FNB30DXD4KXXX
NxB30 40 230 175 149 FNB30DXD3LXXX
NxB30 40 460 FNB30EXD4LXXX
NxB37 50 230 100 234 FNB37DXD3HXXX
NxB37 50 460 FNB37DXD4HXXX
NxB37 50 230 125 203 FNB37DXD3JXXX
NxB37 50 460 FNB37DXD4JXXX
NxB37 50 230 150 193 FNB37DXD3KXXX
NxB37 50 460 FNB37DXD4KXXX
NxB37 50 230 175 180 FNB37DXD3LXXX
NxB37 50 460 FNB37DXD4LXXX








THERE ARE A LOT OF AIR COMPRESSOR BRANDS IN THE WORLD BUT VERY FEW AIR COMPRESSOR SERVICE CENTERS IN DALLAS, FORT WORTH AND SURROUNDING AREAS.  IF YOU ARE LOOKING FOR INDUSTRIAL AIR COMPRESSORS FOR YOUR SHOP, FACTORY, MANUFACTURING PLANT, THEN CALL US AT: 214-428-2868

WE HAVE BEEN IN BUSINESS FOR 50 YEARS.  WE KNOW HOW TO SERVICE, MAINTAIN AND REPAIR ALMOST ALL BRANDS OF INDUSTRIAL PISTON AND ROTARY SCREW AIR COMPRESSORS.

WWW.HKAIRCOMPRESSORS.COM



CHAMPION PARTS

INGERSOLL RAND PARTS

QUINCY PARTS

CURTIS PARTS

ATLAS COPCO PARTS

JENNY PARTS

GARDNER DENVER PARTS

PISTON COMPRESSOR PARTS

ROTARY SCREW PARTS








Call: 214-428-2868




























BRAND SERIES HP VOLT PSI CFM Part Number
CURTIS NX SERIES 125 460 100 554 FRD85FUXXB4H1XXXX
CURTIS NX SERIES 125 460 125 522 FRD85FUXXB4J1XXXX
CURTIS NX SERIES 125 460 150 465 FRD85FUXXB4K1XXXX
CURTIS NX SERIES 150 460 100 731 FRD90FUXXB4H1XXXX
CURTIS NX SERIES 150 460 125 723 FRD90FUXXB4J1XXXX
CURTIS NX SERIES 150 460 150 544 FRD90FUXXB4K1XXXX
CURTIS NX SERIES 200 460 100 930 FRD92MUXXB4H1XXXX
CURTIS NX SERIES 200 460 125 860 FRD92MUXXB4J1XXXX
CURTIS NX SERIES 200 460 150 770 FRD92MUXXB4K1XXXX
CURTIS NX SERIES 250 460 100 1218 FRD93MUXXB4H1XXXX
CURTIS NX SERIES 250 460 125 1050 FRD93MUXXB4J1XXXX
CURTIS NX SERIES 250 460 150 970 FRD93MUXXB4K1XXXX
CURTIS NX SERIES 300 460 100 1360 FRD94MUXXB4H1XXXX
CURTIS NX SERIES 300 460 125 1350 FRD94MUXXB4J1XXXX
CURTIS NX SERIES 300 460 150 1050 FRD94MUXXB4K1XXXX
CURTIS NX SERIES 125 460 100 554 FRD85FEXXB4H1XXXX
CURTIS NX SERIES 125 460 125 522 FRD85FEXXB4J1XXXX
CURTIS NX SERIES 125 460 150 465 FRD85FEXXB4K1XXXX
CURTIS NX SERIES 150 460 100 731 FRD90FEXXB4H1XXXX
CURTIS NX SERIES 150 460 125 723 FRD90FEXXB4J1XXXX
CURTIS NX SERIES 150 460 150 544 FRD90FEXXB4K1XXXX
CURTIS NX SERIES 200 460 100 930 FRD92MEXXB4H1XXXX
CURTIS NX SERIES 200 460 125 860 FRD92MEXXB4J1XXXX
CURTIS NX SERIES 200 460 150 770 FRD92MEXXB4K1XXXX
CURTIS NX SERIES 250 460 100 1218 FRD93MEXXB4H1XXXX
CURTIS NX SERIES 250 460 125 1050 FRD93MEXXB4J1XXXX
CURTIS NX SERIES 250 460 150 970 FRD93MEXXB4K1XXXX
CURTIS NX SERIES 300 460 100 1360 FRD94MEXXB4H1XXXX
CURTIS NX SERIES 300 460 125 1350 FRD94MEXXB4J1XXXX
CURTIS NX SERIES 300 460 150 1050 FRD94MEXXB4K1XXXX
























THERE ARE A LOT OF AIR COMPRESSOR BRANDS IN THE WORLD BUT VERY FEW AIR COMPRESSOR SERVICE CENTERS IN DALLAS, FORT WORTH AND SURROUNDING AREAS.  IF YOU ARE LOOKING FOR INDUSTRIAL AIR COMPRESSORS FOR YOUR SHOP, FACTORY, MANUFACTURING PLANT, THEN CALL US AT: 214-428-2868
WE HAVE BEEN IN BUSINESS FOR 50 YEARS.  WE KNOW HOW TO SERVICE, MAINTAIN AND REPAIR ALMOST ALL BRANDS OF INDUSTRIAL PISTON AND ROTARY SCREW AIR COMPRESSORS.
WWW.HKAIRCOMPRESSORS.COM








These are some of the best selling industrial air compressors on the market today.  Curtis compressors are made in St. Louis, MO. and have been making industrial air compressors in the USA since 1854.











Model HP VOLT  PSI CFM Part Number
NxB30 40 230 100 196 FNB30DXX3HXXX
NxB30 40 460 FNB30DXX4HXXX
NxB30 40 230 125 173 FNB30DXX3JXXX
NxB30 40 460 FNB30DXX4JXXX
NxB30 40 230 150 163 FNB30DXX3KXXX
NxB30 40 460 FNB30DXX4KXXX
NxB30 40 230 175 149 FNB30DXX3LXXX
NxB30 40 460 FNB30DXX4LXXX
NxB37 50 230 100 234 FNB37DXX3HXXX
NxB37 50 460 FNB37DXX4HXXX
NxB37 50 230 125 203 FNB37DXX3JXXX
NxB37 50 460 FNB37DXX4JXXX
NxB37 50 230 150 193 FNB37DXX3KXXX
NxB37 50 460 FNB37DXX4KXXX
NxB37 50 230 175 180 FNB37DXX3LXXX
NxB37 50 460 FNB37DXX4LXXX
NxB30 40 230 100 196 FNB30DXD3HXXX
NxB30 40 460 FNB30DXD4HXXX
NxB30 40 230 125 173 FNB30DXD3JXXX
NxB30 40 460 FNB30DXD4JXXX
NxB30 40 230 150 163 FNB30DXD3KXXX
NxB30 40 460 FNB30DXD4KXXX
NxB30 40 230 175 149 FNB30DXD3LXXX
NxB30 40 460 FNB30EXD4LXXX
NxB37 50 230 100 234 FNB37DXD3HXXX
NxB37 50 460 FNB37DXD4HXXX
NxB37 50 230 125 203 FNB37DXD3JXXX
NxB37 50 460 FNB37DXD4JXXX
NxB37 50 230 150 193 FNB37DXD3KXXX
NxB37 50 460 FNB37DXD4KXXX
NxB37 50 230 175 180 FNB37DXD3LXXX
NxB37 50 460 FNB37DXD4LXXX
NX SERIES 125 460 100 554 FRD85FUXXB4H1XXXX
NX SERIES 125 460 125 522 FRD85FUXXB4J1XXXX
NX SERIES 125 460 150 465 FRD85FUXXB4K1XXXX
NX SERIES 150 460 100 731 FRD90FUXXB4H1XXXX
NX SERIES 150 460 125 723 FRD90FUXXB4J1XXXX
NX SERIES 150 460 150 544 FRD90FUXXB4K1XXXX
NX SERIES 200 460 100 930 FRD92MUXXB4H1XXXX
NX SERIES 200 460 125 860 FRD92MUXXB4J1XXXX
NX SERIES 200 460 150 770 FRD92MUXXB4K1XXXX
NX SERIES 250 460 100 1218 FRD93MUXXB4H1XXXX
NX SERIES 250 460 125 1050 FRD93MUXXB4J1XXXX
NX SERIES 250 460 150 970 FRD93MUXXB4K1XXXX
NX SERIES 300 460 100 1360 FRD94MUXXB4H1XXXX
NX SERIES 300 460 125 1350 FRD94MUXXB4J1XXXX
NX SERIES 300 460 150 1050 FRD94MUXXB4K1XXXX
NX SERIES 125 460 100 554 FRD85FEXXB4H1XXXX
NX SERIES 125 460 125 522 FRD85FEXXB4J1XXXX
NX SERIES 125 460 150 465 FRD85FEXXB4K1XXXX
NX SERIES 150 460 100 731 FRD90FEXXB4H1XXXX
NX SERIES 150 460 125 723 FRD90FEXXB4J1XXXX
NX SERIES 150 460 150 544 FRD90FEXXB4K1XXXX
NX SERIES 200 460 100 930 FRD92MEXXB4H1XXXX
NX SERIES 200 460 125 860 FRD92MEXXB4J1XXXX
NX SERIES 200 460 150 770 FRD92MEXXB4K1XXXX
NX SERIES 250 460 100 1218 FRD93MEXXB4H1XXXX
NX SERIES 250 460 125 1050 FRD93MEXXB4J1XXXX
NX SERIES 250 460 150 970 FRD93MEXXB4K1XXXX
NX SERIES 300 460 100 1360 FRD94MEXXB4H1XXXX
NX SERIES 300 460 125 1350 FRD94MEXXB4J1XXXX
NX SERIES 300 460 150 1050 FRD94MEXXB4K1XXXX
NX SERIES 50 460 100 228 FRD50FUXXA4H1XXXX
NX SERIES 50 460 125 212 FRD50FUXXA4J1XXXX
NX SERIES 50 460 150 188 FRD50FUXXA4K1XXXX
NX SERIES 50 460 175 174 FRD50FUXXA4L1XXXX
NX SERIES 60 460 100 295 FRD60FUXXA4H1XXXX
NX SERIES 60 460 125 272 FRD60FUXXA4J1XXXX
NX SERIES 60 460 150 227 FRD60FUXXA4K1XXXX
NX SERIES 60 460 175 200 FRD60FUXXA4L1XXXX
NX SERIES 75 460 100 357 FRD75FUXXA4H1XXXX
NX SERIES 75 460 125 330 FRD75FUXXA4J1XXXX
NX SERIES 75 460 150 312 FRD75FUXXA4K1XXXX
NX SERIES 75 460 175 251 FRD75FUXXA4L1XXXX
NX SERIES 100 460 100 457 FRD80FUXXA4H1XXXX
NX SERIES 100 460 125 438 FRD80FUXXA4J1XXXX
NX SERIES 100 460 150 374 FRD80FUXXA4K1XXXX
NX SERIES 100 460 175 337 FRD80FUXXA4L1XXXX
NX SERIES 50 460 100 228 FRD50FEXXA4H1XXXX
NX SERIES 50 460 125 212 FRD50FEXXA4J1XXXX
NX SERIES 50 460 150 188 FRD50FEXXA4K1XXXX
NX SERIES 50 460 175 174 FRD50FEXXA4L1XXXX
NX SERIES 60 460 100 295 FRD60FEXXA4H1XXXX
NX SERIES 60 460 125 272 FRD60FEXXA4J1XXXX
NX SERIES 60 460 150 227 FRD60FEXXA4K1XXXX
NX SERIES 60 460 175 200 FRD60FEXXA4L1XXXX
NX SERIES 75 460 100 357 FRD75FEXXA4H1XXXX
NX SERIES 75 460 125 330 FRD75FEXXA4J1XXXX
NX SERIES 75 460 150 312 FRD75FEXXA4K1XXXX
NX SERIES 75 460 175 251 FRD75FEXXA4L1XXXX
NX SERIES 100 460 100 457 FRD80FEXXA4H1XXXX
NX SERIES 100 460 125 438 FRD80FEXXA4J1XXXX
NX SERIES 100 460 150 374 FRD80FEXXA4K1XXXX
NX SERIES 100 460 175 337 FRD80FEXXA4L1XXXX
NX SERIES 15 460 100 69 FRB15FU8XA4H1XXXX
NX SERIES 15 460 125 59 FRB15FU8XA4J1XXXX
NX SERIES 15 460 150 51 FRB15FU8XA4K1XXXX
NX SERIES 15 460 175 45 FRB15FU8XA4L1XXXX
NX SERIES 20 460 100 92 FRB20FU1XA4H1XXXX
NX SERIES 20 460 125 81 FRB20FU1XA4J1XXXX
NX SERIES 20 460 150 76 FRB20FU1XA4K1XXXX
NX SERIES 20 460 175 65 FRB20FU1XA4L1XXXX
NX SERIES 25 460 100 111 FRB25FU1XA4H1XXXX
NX SERIES 25 460 125 104 FRB25FU1XA4J1XXXX
NX SERIES 25 460 150 92 FRB25FU1XA4K1XXXX
NX SERIES 25 460 175 84 FRB25FU1XA4L1XXXX
NX SERIES 30 460 100 135 FRB30FU1XA4H1XXXX
NX SERIES 30 460 125 129 FRB30FU1XA4J1XXXX
NX SERIES 30 460 150 115 FRB30FU1XA4K1XXXX
NX SERIES 30 460 175 102 FRB30FU1XA4L1XXXX
NX SERIES 40 460 100 189 FRB40FU2XA4H1XXXXX
NX SERIES 40 460 125 173 FRB40FU2XA4J1XXXXX
NX SERIES 40 460 150 150 FRB40FU2XA4K1XXXXX
NX SERIES 40 460 175 140 FRB40FU2XA4L1XXXXX
NX SERIES 50 460 100 220 FRB50FU2XA4H1XXXX
NX SERIES 50 460 125 200 FRB50FU2XA4J1XXXX
NX SERIES 50 460 150 186 FRB50FU2XA4K1XXXX
NX SERIES 50 460 175 170 FRB50FU2XA4L1XXXX
NX SERIES 15 460 100 69 FRB15FE8XA4H1XXXX
NX SERIES 15 460 125 59 FRB15FE8XA4J1XXXX
NX SERIES 15 460 150 51 FRB15FE8XA4K1XXXX
NX SERIES 15 460 175 45 FRB15FE8XA4L1XXXX
NX SERIES 20 460 100 92 FRB20FE1XA4H1XXXX
NX SERIES 20 460 125 81 FRB20FE1XA4J1XXXX
NX SERIES 20 460 150 76 FRB20FE1XA4K1XXXX
NX SERIES 20 460 175 65 FRB20FE1XA4L1XXXX
NX SERIES 25 460 100 111 FRB25FE1XA4H1XXXX
NX SERIES 25 460 125 104 FRB25FE1XA4J1XXXX
NX SERIES 25 460 150 92 FRB25FE1XA4K1XXXX
NX SERIES 25 460 175 84 FRB25FE1XA4L1XXXX
NX SERIES 30 460 100 135 FRB30FE1XA4H1XXXX
NX SERIES 30 460 125 129 FRB30FE1XA4J1XXXX
NX SERIES 30 460 150 115 FRB30FE1XA4K1XXXX
NX SERIES 30 460 175 102 FRB30FE1XA4L1XXXX
NX SERIES 40 460 100 189 FRB40FE2XA4H1XXXXX
NX SERIES 40 460 125 173 FRB40FE2XA4J1XXXXX
NX SERIES 40 460 150 150 FRB40FE2XA4K1XXXXX
NX SERIES 40 460 175 140 FRB40FE2XA4L1XXXXX
NX SERIES 50 460 100 220 FRB50FE2XA4H1XXXX
NX SERIES 50 460 125 200 FRB50FE2XA4J1XXXX
NX SERIES 50 460 150 186 FRB50FE2XA4K1XXXX
NX SERIES 50 460 175 170 FRB50FE2XA4L1XXXX
NxB04 5 230/1 FNB04A6X2HXXX
NxB04 5 230/3 100 22 FNB04A6X3HXXX
NxB04 5 460/3 FNB04A6X4HXXX
NxB04 5 230/1 FNB04A6X2JXXX
NxB04 5 230/3 125 20 FNB04A6X3JXXX
NxB04 5 460/3 FNB04A6X4JXXX
NxB04 5 230/1 FNB04A6X2KXXX
NxB04 5 230/3 150 17 FNB04A6X3KXXX
NxB04 5 460/3 FNB04A6X4KXXX
NxB04 5 230/1 FNB04A6X2LXXX
NxB04 5 230/3 175 15 FNB04A6X3LXXX
NxB04 5 460/3 FNB04A6X4LXXX
NxB06 7.5 230/1 FNB06A6X2HXXX
NxB06 7.5 230/3 100 29 FNB06A6X3HXXX
NxB06 7.5 460/3 FNB06A6X4HXXX
NxB06 7.5 230/1 FNB06A6X2JXXX
NxB06 7.5 230/3 125 27 FNB06A6X3JXXX
NxB06 7.5 460/3 FNB06A6X4JXXX
NxB06 7.5 230/1 FNB06A6X2KXXX
NxB06 7.5 230/3 150 24 FNB06A6X3KXXX
NxB06 7.5 460/3 FNB06A6X4KXXX
NxB06 7.5 230/1 FNB06A6X2LXXX
NxB06 7.5 230/3 175 22 FNB06A6X3LXXX
NxB06 7.5 460/3 FNB06A6X4LXXX
NxB04 5 230/1 FNB04A6U2HXXX
NxB04 5 230/3 100 22 FNB04A6U3HXXX
NxB04 5 460/3 FNB04A6U4HXXX
NxB04 5 230/1 FNB04A6U2JXXX
NxB04 5 230/3 125 20 FNB04A6U3JXXX
NxB04 5 460/3 FNB04A6U4JXXX
NxB04 5 230/1 FNB04A6U2KXXX
NxB04 5 230/3 150 17 FNB04A6U3KXXX
NxB04 5 460/3 FNB04A6U4KXXX
NxB04 5 230/1 FNB04A6U2LXXX
NxB04 5 230/3 175 15 FNB04A6U3LXXX
NxB04 5 460/3 FNB04A6U4LXXX
NxB06 7.5 230/1 FNB06A6U2HXXX
NxB06 7.5 230/3 100 29 FNB06A6U3HXXX
NxB06 7.5 460/3 FNB06A6U4HXXX
NxB06 7.5 230/1 FNB06A6U2JXXX
NxB06 7.5 230/3 125 27 FNB06A6U3JXXX
NxB06 7.5 460/3 FNB06A6U4JXXX
NxB06 7.5 230/1 FNB06A6U2KXXX
NxB06 7.5 230/3 150 24 FNB06A6U3KXXX
NxB06 7.5 460/3 FNB06A6U4KXXX
NxB06 7.5 230/1 FNB06A6U2LXXX
NxB06 7.5 230/3 175 22 FNB06A6U3LXXX
NxB06 7.5 460/3 FNB06A6U4LXXX












NxB08 10 230 FNB08B8X3HXXX
NxB08 10 460 100 45 FNB08B8X4HXXX
NxB08 10 230 FNB08B8X3JXXX
NxB08 10 460 125 42 FNB08B8X4JXXX
NxB08 10 230 FNB08B8X3KXXX
NxB08 10 460 150 37 FNB08B8X4KXXX
NxB08 10 230 FNB08B8X3LXXX
NxB08 10 460 175 33 FNB08B8X4LXXX
NxB11 15 230 FNB11B8X3HXXX
NxB11 15 460 100 63 FNB11B8X4HXXX
NxB11 15 230 FNB11B8X3JXXX
NxB11 15 460 125 58 FNB11B8X4JXXX
NxB11 15 230 FNB11B8X3KXXX
NxB11 15 460 150 50 FNB11B8X4KXXX
NxB11 15 230 FNB11B8X3LXXX
NxB11 15 460 175 45 FNB11B8X4LXXX
NxB15 20 230 FNB15B8X3HXXX
NxB15 20 460 100 82 FNB15B8X4HXXX
NxB15 20 230 FNB15B8X3JXXX
NxB15 20 460 125 77 FNB15B8X4JXXX
NxB15 20 230 FNB15B8X3KXXX
NxB15 20 460 150 72 FNB15B8X4KXXX
NxB15 20 230 FNB15B8X3LXXX
NxB15 20 460 175 62 FNB15B8X4LXXX
NxB08 10 230 FNB08B8U3HXXX
NxB08 10 460 100 45 FNB08B8U4HXXX
NxB08 10 230 FNB08B8U3JXXX
NxB08 10 460 125 42 FNB08B8U4JXXX
NxB08 10 230 FNB08B8U3KXXX
NxB08 10 460 150 37 FNB08B8U4KXXX
NxB08 10 230 FNB08B8U3LXXX
NxB08 10 460 175 33 FNB08B8U4LXXX
NxB11 15 230 FNB11B8U3HXXX
NxB11 15 460 100 63 FNB11B8U4HXXX
NxB11 15 230 FNB11B8U3JXXX
NxB11 15 460 125 58 FNB11B8U4JXXX
NxB11 15 230 FNB11B8U3KXXX
NxB11 15 460 150 50 FNB11B8U4KXXX
NxB11 15 230 FNB11B8U3LXXX
NxB11 15 460 175 45 FNB11B8U4LXXX
NxB15 20 230 FNB15B8U3HXXX
NxB15 20 460 100 82 FNB15B8U4HXXX
NxB15 20 230 FNB15B8U3JXXX
NxB15 20 460 125 77 FNB15B8U4JXXX
NxB15 20 230 FNB15B8U3KXXX
NxB15 20 460 150 72 FNB15B8U4KXXX
NxB15 20 230 FNB15B8U3LXXX
NxB15 20 460 175 62 FNB15B8U4LXXX























NxD75 100 460 100 495 FND75FXX4HXPC
NxD75 100 575 FND75FXX8HXPC
NxD75 100 460 125 437 FND75FXX4JXPC
NxD75 100 575 FND75FXX8JXPC
NxD75 100 460 150 416 FND75FXX4KXPC
NxD75 100 575 FND75FXX8KXPC
NxD75 100 460 175 382 FND75FXX4LXPC
NxD75 100 575 FND75FXX8LXPC
NxD90 125 460 100 553 FND90FXX4HXPC
NxD90 125 575 FND90FXX8HXPC
NxD90 125 460 125 492 FND90FXX4JXPC
NxD90 125 575 FND90FXX8JXPC
NxD90 125 460 150 448 FND90FXX4KXPC
NxD90 125 575 FND90FXX8KXPC
NxD90 125 460 175 424 FND90FXX4LXPC
NxD90 125 575 FND90FXX8LXPC
NxD110 150 460 125 622 FND110GXX4JXPC
NxD160 200 460 125 938 FND160HXX4JXPC
NxD185 250 460 125 1029 FND185HXX4JXPC
NxHE90 125 460 125 632 FHE90GXX4JXPC
NxHE110 150 460 125 755 FHE110GXX4JXPC
NxHE132 175 460 125 904 FHE132GXX4JXPC
NxHE160 200 460 125 1119 FHE160HXX4JXPC
NxHE185 250 460 125 1267 FHE185HXX4JXPC
NxHE200 275 460 125 1373 FHE200IXX4JXPC
NxHE220 300 460 125 1507 FHE220IXX4JXPC
NxHE260 350 460 125 1748 FHE260IXX4JXPC
NxV08 10 460 100 45-17 FNV08B8X4HXPC
NxV08 10 460 125 42-17 FNV08B8X4JXPC
NxV08 10 460 150 33-17 FNV08B8X4KXPC
NxV08 10 460 175 25-16 FNV08B8X4LXPC
NxV11 15 460 100 63-17 FNV11B8X4HXPC
NxV11 15 460 125 58-17 FNV11B8X4JXPC
NxV11 15 460 150 50-16 FNV11B8X4KXPC
NxV11 15 460 175 44-16 FNV11B8X4LXPC
NxV15 20 460 100 82-17 FNV15B8X4HXPC
NxV15 20 460 125 77-17 FNV15B8X4JXPC
NxV15 20 460 150 72-17 FNV15B8X4KXPC
NxV15 20 460 175 60-16 FNV15B8X4LXPC
NxV08 10 460 100 45-17 FNV08BXX4HXPC
NxV08 10 460 125 42-17 FNV08BXX4JXPC
NxV08 10 460 150 33-17 FNV08BXX4KXPC
NxV08 10 460 175 25-16 FNV08BXX4LXPC
NxV11 15 460 100 63-17 FNV11BXX4HXPC
NxV11 15 460 125 58-17 FNV11BXX4JXPC
NxV11 15 460 150 50-16 FNV11BXX4KXPC
NxV11 15 460 175 44-16 FNV11BXX4LXPC
NxV15 20 460 100 82-17 FNV15BXX4HXPC
NxV15 20 460 125 77-17 FNV15BXX4JXPC
NxV15 20 460 150 72-17 FNV15BXX4KXPC
NxV15 20 460 175 60-16 FNV15BXX4LXPC
NxV18 25 460 100 112-33 FNV18C1X4HXPC
NxV18 25 460 125 102-33 FNV18C1X4JXPC
NxV18 25 460 150 91-44 FNV18C1X4KXPC
NxV18 25 460 175 83-40 FNV18C1X4LXPC
NxV22 30 460 100 129-34 FNV22C1X4HXPC
NxV22 30 460 125 118-33 FNV22C1X4JXPC
NxV22 30 460 150 112-32 FNV22C1X4KXPC
NxV22 30 460 175 105-40 FNV22C1X4LXPC
NxV18 25 460 100 112-33 FNV18CXX4HXPC
NxV18 25 460 125 102-33 FNV18CXX4JXPC
NxV18 25 460 150 91-44 FNV18CXX4KXPC
NxV18 25 460 175 83-40 FNV18CXX4LXPC
NxV22 30 460 100 129-34 FNV22CXX4HXPC
NxV22 30 460 125 118-33 FNV22CXX4JXPC
NxV22 30 460 150 112-32 FNV22CXX4KXPC
NxV22 30 460 175 105-40 FNV22CXX4LXPC
NxV30 40 460 100 183-52 FNV30DXX4HXPC
NxV30 40 460 125 169-51 FNV30DXX4JXPC
NxV30 40 460 150 153-50 FNV30DXX4KXPC
NxV30 40 460 175 135-48 FNV30DXX4LXPC
NxV37 50 460 100 227-52 FNV37DXX4HXPC
NxV37 50 460 125 210-51 FNV37DXX4JXPC
NxV37 50 460 150 189-50 FNV37DXX4KXPC
NxV37 50 460 175 168-48 FNV37DXX4LXPC
NxV45 60 460 100 288.3-63.5 FNV45EXX4HXPC
NxV45 60 460 125 262.7-70.5 FNV45EXX4JXPC
NxV45 60 460 150 244.7-64.2 FNV45EXX4KXPC
NxV55 75 460 100 345.4-71.3 FNV55EXX4HXPC
NxV55 75 460 125 314.2-94.0 FNV55EXX4JXPC
NxV55 75 460 150 277.4-122.3 FNV55EXX4KXPC
NxV75 100 460 100 498.8-120.7 FNV75FXX4HXPC
NxV75 100 460 125 450.8-119.7 FNV75FXX4JXPC
NxV75 100 460 150 411.3-117.4 FNV75FXX4KXPC
NxV90 125 460 100 567.3-120.7 FNV90FXX4HXPC
NxV90 125 460 125 505.5-119.7 FNV90FXX4JXPC
NxV90 125 460 150 456.5-117.5 FNV90FXX4KXPC
NxV110 150 460 100 * FNV110GXX4HXPC
NxV110 150 460 125 * FNV110GXX4JXPC
NxV110 150 460 150 * FNV110GXX4KXPC
NxV160 200 460 115 * FNV160HXX4JXPC
NxV185 250 460 115 * FNV185HXX4JXPC
RS SERIES     15 460 100 69 FRB15FUXXA4H1XXXX
RS SERIES     15 460 125 59 FRB15FUXXA4J1XXXX
RS SERIES     15 460 150 51 FRB15FUXXA4K1XXXX
RS SERIES     15 460 175 45 FRB15FUXXA4L1XXXX
RS SERIES     20 460 100 92 FRB20FUXXA4H1XXXX
RS SERIES     20 460 125 81 FRB20FUXXA4J1XXXX
RS SERIES     20 460 150 76 FRB20FUXXA4K1XXXX
RS SERIES     20 460 175 65 FRB20FUXXA4L1XXXX
RS SERIES     25 460 100 111 FRB25FUXXA4H1XXXX
RS SERIES     25 460 125 104 FRB25FUXXA4J1XXXX
RS SERIES     25 460 150 92 FRB25FUXXA4K1XXXX
RS SERIES     25 460 175 84 FRB25FUXXA4L1XXXX
RS SERIES     30 460 100 135 FRB30FUXXA4H1XXXX
RS SERIES     30 460 125 129 FRB30FUXXA4J1XXXX
RS SERIES     30 460 150 115 FRB30FUXXA4K1XXXX
RS SERIES     30 460 175 102 FRB30FUXXA4L1XXXX
RS SERIES     40 460 100 189 FRB40FUXXA4H1XXXX
RS SERIES     40 460 125 173 FRB40FUXXA4J1XXXX
RS SERIES     40 460 150 150 FRB40FUXXA4K1XXXX
RS SERIES     40 460 175 140 FRB40FUXXA4L1XXXX
RS SERIES     50 460 100 220 FRB50FUXXA4H1XXXX
RS SERIES     50 460 125 200 FRB50FUXXA4J1XXXX
RS SERIES     50 460 150 186 FRB50FUXXA4K1XXXX
RS SERIES     50 460 175 170 FRB50FUXXA4L1XXXX
RS SERIES     15 460 100 69 FRB15FU8XA4H1XXXX
RS SERIES     15 460 125 59 FRB15FU8XA4J1XXXX
RS SERIES     15 460 150 51 FRB15FU8XA4K1XXXX
RS SERIES     15 460 175 45 FRB15FU8XA4L1XXXX
RS SERIES     20 460 100 92 FRB20FU1XA4H1XXXX
RS SERIES     20 460 125 81 FRB20FU1XA4J1XXXX
RS SERIES     20 460 150 76 FRB20FU1XA4K1XXXX
RS SERIES     20 460 175 65 FRB20FU1XA4L1XXXX
RS SERIES     25 460 100 111 FRB25FU1XA4H1XXXX
RS SERIES     25 460 125 104 FRB25FU1XA4J1XXXX
RS SERIES     25 460 150 92 FRB25FU1XA4K1XXXX
RS SERIES     25 460 175 84 FRB25FU1XA4L1XXXX
RS SERIES     30 460 100 135 FRB30FU1XA4H1XXXX
RS SERIES     30 460 125 129 FRB30FU1XA4J1XXXX
RS SERIES     30 460 150 115 FRB30FU1XA4K1XXXX
RS SERIES     30 460 175 102 FRB30FU1XA4L1XXXX
RS SERIES     40 460 100 189 FRB40FU2XA4H1XXXXX
RS SERIES     40 460 125 173 FRB40FU2XA4J1XXXXX
RS SERIES     40 460 150 150 FRB40FU2XA4K1XXXXX
RS SERIES     40 460 175 140 FRB40FU2XA4L1XXXXX



















THERE ARE A LOT OF AIR COMPRESSOR BRANDS IN THE WORLD BUT VERY FEW AIR COMPRESSOR SERVICE CENTERS IN DALLAS, FORT WORTH AND SURROUNDING AREAS.  IF YOU ARE LOOKING FOR INDUSTRIAL AIR COMPRESSORS FOR YOUR SHOP, FACTORY, MANUFACTURING PLANT, THEN CALL US AT: 214-428-2868
WE HAVE BEEN IN BUSINESS FOR 50 YEARS.  WE KNOW HOW TO SERVICE, MAINTAIN AND REPAIR ALMOST ALL BRANDS OF INDUSTRIAL PISTON AND ROTARY SCREW AIR COMPRESSORS.
WWW.HKAIRCOMPRESSORS.COM
















Best selling industrial rotary screw compressors in the world with the best warranties on the planet.  Curtis (FSCURTIS) have been making industrial compressors since 1854.  The compressors are extremely easy to work on and parts are readily available since Curtis is headquartered in St. Louis, MO.  Most of the other top brands are made in China such as Ingersoll Rand; and many of the rotary screw manufacturers lock out other technicians from accessing their compressors.  Essentially, they hold the client hostage only using their technicians and parts..



The FSCURTIS Rotary Screw Compressor is the most efficient and quietest screw compressor on the planet.  It comes with a 10 year warranty on the air-end.



CALL: 214-428-2868 OR VISIT OUR WEBSITE:

































H&K SERVICES ALL TYPES OF  PISTON, ROTARY SCREW, AND CLIMATE CONTROL COMPRESSORS.  IF YOU ARE LOOKING FOR A NEW ROTARY SCREW, MOBILE GAS COMPRESSOR; OR JUST NEED SOMEONE TO REBUILD YOUR COMPRESSOR PUMP;
CALL: 214-428-2868
Rotary Screw Air Compressors
