RS SERIES 50HP ROTARY SCREW AIR COMPRESSORS









RSD50 HORSEPOWER - 300HP ROTARY SCREW AIR COMPRESSOR
OPERATIONS MANUAL





ROTARY SCREW COMPRESSOR



DESCRIPTION QUANTITY RS40  RS50
1 BASE 42 X 72 DARK GREY RS40-50F, 50D 1 RN10116-15 <
2 TANK AIR/OIL SEPARATOR 14" DIA 19 GAL 1 RN10222-2 <
3 AIR END BSA32 EU DESIGN 1 CS950-3 <
MOTOR, 3PHASE, 60HZ, 200V, ODP RN19045 RN19051-2
4 MOTOR, 3PHASE, 60 HZ, 230/460V ODP 1 RN19041 RN19051
MOTOR, 3PHASE, 60HZ, 575V, ODP RN19041-5 RN19051-5
MOTOR 1 1/2HP, 3 PHASE, 60HZ, 200V ODP RN19001-7 VM723
5 MOTOR 1 1/2HP, 3 PHASE, 60HZ, 230/460V ODP 1 M20 M25
MOTOR 1 1/2HP, 3 PHASE, 60HZ, 575V ODP RN19001-11 VM722
6 FAN SHROUD R/S 50 1 CS730 <
7 COOLER SUPPORT-LEFT 1 CS700 <
8 COOLER AIR/OIL (R/S 40-50) 1 RN32217 <
9 FAN MOTOR MOUNT R/S 40-50 1 RN10120-8 <
10 BRACKET, OIL FILTER 1 CS717A <
11 SUPPORT, ELECTRICAL ENCL. 39" 2 CS677-2 <
12 BELTGUARD, BACK BSA32 R/S40-50F 1 RN10510-11 <
13 GUARD BELT FRONT R/S 40-50 1 RN10510 <
14 INLET VALVE RH60P 2.5" W/MOD ORIF 0.8mm, 110V 1 RN24571 <
14A O-RING FOR RN24571 1 INCLUDED <
14B O-RING FOR RN24571 1 INCLUDED <
15 MOTOR BASE 40HP ODP/30HP TEFC 1 RN12030 RN12040
16 GUARD FAN  24 " RD WIRE 1 RN10456 <
17 SEPARATOR, ELEMENT 1 RN27518 <
18 TUBE 1 1/2" O.D. 1 OFE981 <
19 MOUNT BSA32 BASE BOLTED 1 RN10170 <
20 TUBE-BY-PASS TO OIL FILTER 3/4" OD. 1 OFE959 <
21 TUBE 1 1/4" O.D.X 0.049 1 OFE992-1 <
22 TUBE-SEPARATOR TANK TO BY-PASS 3/4"OD 1 OFE960 <
CONTROL PANEL SIZE "K" 1330000 <
23 1
CONTROL PANEL SIZE "N" 1330001 <
24 PLUG PLASTIC, 2"SQ.TUBE 2 103004 <
25 BONDED SEAL FOR M26, VITON 1 VAB788-1 <
26 CONNECTOR M26-1.5 X 3/4" JIC 37'FL. STR 1 VAB788 <
27 BONDED SEAL FOR M10, VITON 1 VAB789-1 <
28 ADAPTER M10-1 X 1/4"NPTF VITON BSA22-32 1 VAB789 <
29 ELBOW, MALE 90 DEGREE 1/4"  NPTM X 1/4" NPTM STEEL 1 VAA754 <
30 VALVE-CHECK IN LINE 1/4 X 1/4 NPT (OLD# RN42110) 1 VV834 <
3
CAP297
31 ORIFICE SCAVENGER COMPRESSION CONNECTOR ELBOW 5/64(0.078) 1 RN52131-3 <
32 THERMOWELL TEMP SW-GAGE M12X1.5, 7/16-24UNS, 6MM 1 RN18690 <
33 COOPER SEAL FOR THERMOWELL M12X1.5 1 RN18690-1 <
34 NIPPLE 1 1/4 X 5 1/2 1 VA13GHA <
35 CONNECTOR, 1/4OD X 1/4NPT, MALE, ELBOW 2 RN52150-2 <
36 VALVE MIN PRESS 1 1/4" 1 RN42126 <
36A KIT REPAIR MIN. PRESSURE VALVE 1 RN42126-1 <
37 PRESSURE-AIR GAUGE, 300 PSI 2 1/2 " 2 RN30323 <
38 CONNECTOR 1 1/4"NPT X 1 1/4"OD ELBOW-MALE 1 VAA722 <
39 TEE REDUCING 1 X 3/4 X 3/4 1 VAE803 <
40 NIPPLE-BLACK 1 X 5 1/2" 1 VA13FKV <
41 CONNECTOR 3/4"NPT X 3/4"OD.STRAIGHT 1 VAA717 <
42 FAN-ASSY 45 DEG PITCH 1 RN32419 RN32406
43 DRAIN COCK 1/4" 1 VV514 <
44 HHCS 5/16-18 X 1" GRADE 5 ZINC PLATED 13 VH12HH1 <
45 FLAT WASHER 5/16 ZINC PLATED 11 VH32H1 <
46 WASHER-CUT-FLAT 1/4" 7 VH32F <
47 LOCK WASHER ZINC PLATED 1/4" MEDIUM 19 VH35F1 <
48 HHCS 1/4-20 X 3/4" LONG ZINC PLATED 21 VH12FF1 <
49 LOCK WASHER 5/16 SPLIT ZINC PLATED 13 VH35H1 <
50 NUT HEX 5/16-18 ZINC PLATED 7 VH15H1 <
51 NUT-HEX 10-24 4 4440 <
52 GUARD CLIPS 4 RN10455-1 <
53 SCREW-HEX HD. MACHINE 10-24 4 VH11DD <
54 SPIN ON OIL FILTER, R/S 15-50 1 RN28201 <
55 FILTER HEAD OIL (RS15-50) 1 RN28100 <
56 NIPPLE-BLACK 3/4 X 2 1/2" 1 VA13EDA <
57 CONNECTOR 3/4"NPT X 3/4 OD ELBOW 90 DEGREE 1 RN60084 <
58 HHCS M16 X 1.75 X 35MM"  ZINC PLATED 4 VH1479 <
59 WASHER CUT M12 ZINC PLATED 6 VH1239 <
60 VALVE RELIEF 1/2" 200 PSIG 1 RN42817 <
61 ELBOW-1/2" STREET-BLACK 1 VA08DP <
62 HHCS 3/8-16 X 1" GRADE 5  ZINC PLATED 4 VH12HF1 <
63 LOCKWASHER 3/8" ZINC PLATED 4 VH35K1 <
64 WASHER FLAT 3/8" ZINC PLATED 4 VH32K1 <
65 CAP-OIL FILLER/SIGHT GLASS 1 CS741 <
66 COMBINATION OIL FILL AND SIGHT GLASS 1 RN52171 <
67 ADAPTOR STR ELBW  1 1/16-12 UN X 3/4"NPTF 1 RN60078 <
68 BUSHING 3/4 X 1/2 1 VA12EDV <
69 BALL VALVE,1/2",20KG/CM2 1 1475051 <
70 PLUG- SQUARE HEAD-STEEL 1/2" 1 VA01DV <
4
CAP297
71 CONNECTOR ELBOW, 3/4 OD X 1 1/16 - 12UN 2 RN52141 <
72 BUSHING REDUCING 1" X 3/4"  BRASS 1 VA12FEB <
73 ADAPTOR 3/4"NPT X 1 1/16-12UN MALE 1 RN52139 <
74 O-RING SAE12 VITON 1 RN52139-1 <
75 VALVE THERMO SAE12 170 DEG F 1 RN42403 <
76 CONNECTOR 1 1/16"-12UN X 3/4" OD. STRAIGHT, VITON O-RING 1 RN52143 <
77 LOCKWASHER LIGHT 1/2" ZINC PLATED 12 VH35P1 <
78 HHCS 1/2-13UNC X 2 1/2 GRADE 5 4 VH12PS1 <
79 SCREW,1/4-20 X 0.5 HHCS GR 5 4 VH12FH1 <
80 HHCS 1/2-13 X 1 1/4" GRADE 5  ZINC PLATED 4 VH1474 <
81 HHCS 5/8-11UNC X 1 1/2  GRADE 5 4 VH12RM1 <
82 LOCKWASHER SPLIT 5/8" 8 VH35R1 <
83 FLANGE DISCHARGE SAE32 X 24 ELBOW BSA32 1 RN10710 <
84 CONNECTOR 1 1/2"OD X 1 7/8-12 UN STRGHT, VITON O-RING 1 VAB707 <
85 LOCK WASHER 12MM 8 VH1240 <
86 SWITCH TEMP 1/2"NPT-1"PROBE 2 RN18658 <
87 BOLT M12 X 1.75 X 80MM. 4 VH1452 <
88 SHCS M16-2.0X20MM Zn PL 4 VH1478 <
89 ADAPTOR BSA32, VMC-2.5" INLET VALVE RS40-50 1 RN10716 <
90 CLAMP 3 1/8 - 6 2 RN24076-5 <
91 BELT 3VX530 1
92 BUSHING, AIR END 1
93 SHEAVE, AIR END 1 SEE TABLE 1
94 BUSHING QD SK-42 MM 1
95 SHEAVE, MOTOR 1
96 NUT HEX 1/2"-13 4 VH15P1 <
97 HHCS 1/2-13 X 1 1/4" GRADE 5  ZINC PLATED 4 VH12PH1 <
98 FRG AIR CLEANER R/S40-50 1 RN24077 <
99 MOUNT PLATE, HDF 1 RN24079-11 <
100 ROD THREADED M16 X 2.0 1 VL2402 <
101 PLATE MNT, HDF, RS20-50 W/EYE BOLT MOTORS 1 RN24076-9 <
102 ELBOW REDUCING 3.5" X 3" 1 RN24077-3 <
103 NIPPLE, 1/4"NPT X 1 1/2" SHORT 2 VA13BBV <
104 CONNECTOR 1 1/2"OD.X1 7/8"- 12UN ELBOW 1 RN52145 <
105 NIPPLE 1 1/4"NPT X 2 1/2"LONG 1 VA13GDV <
106 CONNECTOR 1 1/4NPT X 1 1/4OD COMPRESSION 1 VA788 <
107 TEE-REDUCING 1 1/4"NPT X 1/2"NPT X 1 1/4"NPT 1 VAD804 <
108 TUBE STEEL 1/4" OD X.030 WALL 1 OFE1016 <
109 NUT 1/4" OD STEEL 2 VAA756 <
110 TUBE STEEL 1/4" OD X.030 WALL SEPARATOR TO SIGHT GLASS 1 OFE963 <
111 HHCS 5/8-11UNC X 1 1/2  GRADE 5 8 VH12RP <


DESCRIPTION Q. RS40 RS50
112 MALE RUN TEE 1/4 OD X 1/4 OD  X 1/4 MPT 2 VA745 <
113 NYLON TUBE 1/4" BLACK 1 VA1626 <
114 NYLON TUBE 1/4" BLACK 1 VA1626 <
115 HOSE ASSEMBLY 5/8ID X 41.75"LG WITH SAE 37 FEMALE SWIVEL 1 RN60717 <
116 INJECTION VALVE ISG2N 1/4" 1 RN24589 <
117 CONNECTOR SCAVENGER COMPR. 1 RN52150-13 <
118 COOLER SUPPORT-RIGHT 1 CS701 <
119 MTG BRACKET 8" DI 1 RN24077-4 <
120 SIGHT GLASS 1 RN52170 <
121 O-RING #246; PACKS OF 5 PCS 1 RN10713-1 <
122 CONNECTOR,1/8"BSPT X Ø6 ELBOW,QD 1 VAC731 <
123 ADAPTOR 3/8 BSPP X 3/8 NPTF 1 VAA770 <
124 WASHER CUT 1/2" ZINC PLATED 4 VH32P1 <
125 CONNECTOR,1/8"BSPT X Ø6 ELBOW,QD 1 VAC730 <
126 NYLON TUBE 3/8" BLACK 1 VA1628 <
127 TEE 1/4"NPT PIPE  GALV. 2 VA10BQ <
128 NYLON TUBE 1/4" BLACK 1 VA1626 <
129 SPACER 1 SEE TABLE 1
130 NYLON TUBE 1/4" BLACK 1 VA1626 <
131 SWITCH-PRESSURE W/O BLEEDER 1/4"NPT 1 1240007 <
132 NIPPLE 1/4 X CLOSE, 304SS 1 VA13BAV <
133 1/4"X1/2" BULKHEAD FITTING 1 RN10616 <
134 CONNECTOR, 1/4OD X 1/4NPT, MALE, STR. 1 RN52150-5 <
135 CONNECTOR 3/8ODX3/8NPT MALE ELBOW 1 RN52150-10 <


AIR COMPRESSOR SERVICE


H&K Pump is a family business that repairs and services air compressors and parts. Our company is also a proud distributor for FS-Curtis, Champion, and other famous brands. Although we are headquartered in Dallas, Texas, we travel throughout the USA.


We offer our products and services to commercial businesses, automotive facilities, and thousands of small business owners who have air compressor needs. Aside from these, we serve the manufacturing sector, as well as the oil and gas industry.

Heavy duty air compressors have been around since the late 1800's and helped spur the growth of America during the Industrial Era. Not much has really changed with the overall design and implementation of the reciprocating air compressor until the dawn of the rotary screw air compressors and the invention of the high temperature refrigerated air dryers. Today, air compressors can virtually run all day and night for years with higher CFM's than ever imagined.





ITEM NO. DESCRIPTION QTY. RSB40 W/C RSB50 W/C
1 BASE 1 RN10116 <
2 SEPARATOR, OIL/AIR 1 RN10222-2 <
4 MOUNTING PLATE, AIR END 1 RN10127 <
6 PANEL, CONTROL 1
SIZE, “K” 1330000 <
SIZE, “N” 1330001 <
7 COOLER, OIL, W/C 1 RN33157 <
8 AFTERCOOLER, W/C 1 CX740 <
9 COOLER SUPPORT ASSEMBLY, L.H. 1 CS700 <
10 COOLER SUPPORT ASSEMBLY, R.H. 1 CS701 <
11 SUPPORT, CONTROL PANEL 2 CS667 <
15 U-BOLT 2 VH2215 <
16 BOLT, M12 4 VH1665 <
17 LOCKWASHER, M12 4 VH1240 <
23 SCREW, HEX WASHER HEAD, ¼-20 x ¾” LG. 13 VH51FF <
24 LOCKWASHER, 1/4" 17 VH35F1 <
25 WASHER, FLAT, 1/4" 4 VH32F1 <
26 SCREW, HEX HEAD CAP, 5/16-18 x 1" LG. 14 VH12HH1 <
27 LOCKWASHER, 5/16" 14 VH35H1 <
28 WASHER, FLAT, 5/16" 14 VH32H1 <
29 BOLT 5/8-11 X 1” 4 VH12QH1 <
31 LOCKWASHER 5/8” 4 VH35R1 <
32 LOCKWASHER, 1/2" 8 VH35P1 <
33 WASHER, FLAT, 1/2" 8 VH32P1 <
34 AIR END SEAL KIT (NOT SHOWN) 1 RN90437-1 <
36 AFTERCOOLER BRACKET 1 RN10171A <
37 AFTERCOOLER BRACKET 1 RN10171B <
38 BOLT 1/2-13 X 2 3/4” LG 4 VA12PS1 <



TABLE 1: SHEAVES, BUSHING AND BELTS
PSI NUBER DESCRIPTION QTY R/S 40 R/S 50
N QTY PART NO. QTY PART NO.
100 97 SHEAVE, MOTOR 1 RN14110 1 RN14138
100 96 BUSHING, MOTOR 1 RN14177-4 1 RN14177-5
100 95 SHEAVE, AIR END 1 RN14106 1 RN14130
100
100 94 BUSHING, AIR END 1 RN14177-9 1 RN14176-6
100 93 BELT 4 RN14316-1 5 RN14315-1
100 132 SPACER 1 1350071 1 1350072
125 97 SHEAVE, MOTOR 1 RN14110 1 RN14141
125 96 BUSHING, MOTOR 1 RN14177-4 1 RN14177-5
125 95 SHEAVE, AIR END 1 EN14109 1 RN14185
125
125 94 BUSHING, AIR END 1 RN14177-9 1 RN14178-4
125 93 BELT 4 RN14316-1 6 RN14315-1
125 132 SPACER 1 1350071 1 1350073
150 97 SHEAVE, MOTOR 1 RN14109 1 RN14138
150 96 BUSHING, MOTOR 1 RN14177-4 1 RN14177-5
150 95 SHEAVE, AIR END 1 RN14110 1 RN14135
150
150 94 BUSHING, AIR END 1 RN14177-9 1 RN14177-9
150 93 BELT 4 RN14316-1 5 RN14316-1
150 132 SPACER 1 1350071 1 1350071
175 97 SHEAVE, MOTOR 1 RN14106 1 RN14138
175 96 BUSHING, MOTOR 1 RN14177-4 1 RN14177-5
175 95 SHEAVE, AIR END 1 RN14110 1 RN14134
175
175 94 BUSHING, AIR END 1 RN14177-9 1 RN14177-9
175 93 BELT 4 RN14316-1 5 RN14316-1
175 132 SPACER 1 1350071 1 1350071







Curtis air compressors was founded in 1854 in St. Louis, Mo. Over the decades, the company and its products have evolved through innovation and new technologies. Today, just as in 1854, FS-Curtis customers can depend on our products for reliable, long-term service. Equally as important, they can depend on getting the best service from H&K PUMP.

Build to work. Built to last. That's the essence of the FS-Curtis reciprocating and rotary screw air compressors. Curtis compressors combine efficient operation with outstanding durability in the most demanding environments. The easy-access design lowers maintenance costs while the top-quality components deliver maximum uptime.





DESCRIPTION QTY RS40 RS50
1 AIR END 1 CS950-1 <
2 FLANGE, DISCHARGE 1 RN10710 <
3 "O" RING #228 1 RN10682-1 <
4 BOLT, M12x 1.75 X80L 4 VH1452 <
5 LOCK WASHER, 12mm 4 VH1240 <
6 O-RING #246 A/E TO ADAPTOR 1 RN10713-1 <
7 BOLT M12-1.75 X 35MM 4 VH1479 <
8 ADAPTOR BSA32 TO INLET VALVE 1 RN10716 <
9 WASHER M12 4 VH1239 <
10 SHCS M16-2.0 X 20MM 4 VH1478 <
11 VALVE, INLET RH60P 1 RN24571 <
12 KIT, SERVICE, INLET VALVE 1 RN24571-6 <
13 ELBOW,1 1/4”NPT STREET 1 VA08GV <
14 NIPPLE, 3/4" NPT X 10" 1 VA13EQV <
15 CONNECTOR, STRAIGHT 1 VAB707 <
16 TUBE, STEEL 1 OFE981 <
17 CONNECTOR, ELBOW 1 RN52145 <
18 CONNECTOR M26-1.5 X 3/4 1 VAB788 <
19 HOSE, ASSEMBLY 1 RN60713 <
20 CONNECTOR, 3/4” OD FL x 3/4" NPT, ELBOW 1 RN60084 <
21 OIL FILTER HEAD 1 RN28100 <
22 ELEMENT, OIL FILTER 1 RN28201 <
23 TEE - 3/4" NPT GALV. 1 VA10EQ <
24 NIPPLE, 3/4" NPT, CLOSE 1 VAI3EAV <
25 CONNECTOR, ELBOW, 3/4" OD x 3/4"NPT 1 VAA718 <
26 TUBE, BY-PASS TO OIL FILTER 1 OFE960 <
27 CONNECTOR, STRAIGHT, 3/4"OD x SAE12 1 RN52143 <
28 ADAPTOR, MALE - 3/4" NPT x SAE12 1 RN52139 <
28A O-RING FOR RN52139 1 RN52139-1 <
29 THERMOWELL, M12-1.5 1 RN18690 <
29A COOPER SEAL RN18690-1 <
30 ELEMENT, SEPARATOR 1 RN27518 <
31 NIPPLE, 1/4 x SHORT 1 VA13BBV <
32 TEE - 1/4" 4 VA10BQ <
33 CONNECTOR, 1/4” ID X 1/4” NPT MALE, ELBOW 2 RN52150-2 <
34 TEE, RUN - 1/4” NPT X 1/4” OD TUBE X 1/4” OD TUBE 2 VA745 <
35 TUBE, NYLON, BLACK, #11, 1/4" O.D. - VA1626 <
36 COMBINATION OIL FILL AND SIGHT GLASS 1 RN52171 <
37 CAP W/ VENT HOLE 1 CS741 <
38 NIPPLE, 1 1/4" NPT x 2 1/2" 1 VA13GDV <
39 VALVE, MINIMUM PRESSURE 1 RN42126-4 <
40 KIT, SERVICE, MINIMUM PRESSURE VALVE 1 RN42126-1 <
41 CONNECTOR, 1 l/4"OD FL x 1 1/4"NPT STR 2 VAB721 <
42 HOSE, 1 l/4"ODX35" 1 1497020 <
43 TEE, 1 1/4"NPT 1 VA10GQ <
44 CONNECTOR, ELBOW, 3/4"OD x SAE12 2 RN52I41 <
45 TUBE, SEPARATOR TANK TO BY-PASS 1 OFE995 <
46 VALVE, THERMO BY-PASS, 170° F 1 RN42403 <
46A KIT, SERVICE, THERMO BY-PASS VALVE, 170° F 1 RN42403-1 <
47 ADAPTOR STR ELBW  1 1/16-12 UN X 3/4’NPTF 1 RN60078 <
48 BUSHING 3/4”NPT X 1/2”NPT 1 VA12EDV <
49 VALVE, BALL-1/2” 1 1475051 <
50 PLUG 1/2” NPT. 1 VA01DV <
51 SWITCH, TEMPERATURE 1/2”NPT 1 RN18658 <
52 SWITCH, TEMPERATURE 1/4”NPT 1 RN18659 <
53 ELBOW, STREET 1/2”NPT 1 VA08DV <
54 AIR GAUGE, 2 1/2” DIA., 1/4”NPT LIQUID FILLED 1 RN30323 <
54A AIR GAUGE, 2 1/2” DIA., 1/4”NPT LIQUID FILLED 1 RN30322 <
55 NIPPLE, 1 1/4” NPT X 10” 1 VA13GQV <
56 COMPRESSION CONNECTOR, 1/4” NPT X 1/4”,SCAV.LINE 1 RN52151 <
57 STEEL TUBE, 1/4” OD 1 OFE963 <
58 STEEL TUBE, 1/4” OD 1 OFE968 <
59 NUT, 1/4” OD, STEEL 2 VAA756 <
60 SLEEVE, 1/4” OD, STEEL 2 VAA757 <
61 SIGHT GLASS 1 RN52174 <
62 ORIFICE SCAVENGER COMPRESSION CONNECTOR 1 RN52131-3 <
63 CHECK VALVE IN-LINE 1/4” 1 VV834 <
64 ELBOW 1/4 NPTM X 1/4” NPTM 1 VAA754 <
65 ADAPTER, M10 X 1/4” NPTF 1 VAB789 <
66 BONDED SEAL FOR VAB789 1 VAB789-1 <
67 VALVE, RELIEF - 1/2” 200 PSI 1 RN42817 <
68 BUSHING, 1 1/4” NPT X 34” NPT 3 VA12GEV <
69 BUSHING, 2” NPT X 1 1/4” NPT 2 VA12JGV <
70 BUSHING, 1 1/2” NPT X 1 1/4” NPT 2 VA12HGV <
71 BUSHING, 3/4” NPT X 1/2” NPT 4 VA12EDV <
72 NIPPLE, 1/2”” NPT, CLOSE. 4 VA13DAV <
73 ELBOW, 1/2” NPT 4 VA06DB <
74 NIPPLE 1/2”NPT X 3” 2 VA13DEV <
75 CONNECTOR, 1/2” (WATER HOSE) 2 RN60071 <
76 HOSE, 1/2” OD, MULTI-PURPOSE 3’ RN60070 <
77 CLAMP, WORM DRIVE HOSE 2 RN60072 <
78 NIPPLE,1 1/4”NPT X 5 1/2”LG 1 VA13GKV <
79 WATER MODULATING VALVE, 1/2” 1 CF1552 <
80 WELL, WATER VALVE, 3/4” X 4 1/2” 1 CF1559 <
81 UNION, 1/2” NPT 1 VAC883 <
83 BULCKHEAD FITTING 1/2”(FOR ENCLOSED UNIT ONLY) 1 RN10617-1 <
84 HOSE 1/2” OD, MULTI PURPOSE(  FOR ENCLOSED UNIT ONLY) 5’ RN60070 <
85 CLAMP, WORM DRIVE HOSE(  FOR ENCLOSED UNIT ONLY) 2 RN60072 <
86 CONNECTOR, 1/2” (WATER HOSE)(  FOR ENCLOSED UNIT ONLY) 2 RN60071 <
87 NIPPLE 3/8”NPT X 1 1/2” SHORT 1 VA13CBV <
88 BALL VALVE 3/8” NPT 1 VV539 <
89 PLUG 3/8”NPT 1 VA03CU <
90 SEPARAOR TANK CROSS (NOT SHOWN) 1 RN10140 <
91 PRESSURE REGULATOR FOR 175 PSI UNIT (NOT SHOWN) 1 CY58-1 <
92 HD AIR FILTER 1 RN24077 <
93 CLAMP 3 1/8-16 2 RN24076-5A <
94 ELBOW 3.5 1 RN24077-5 <
95 MOUNTING BRACKET 8”DIA 1 RN24077-4 <
96 MOUNTING PLATE  MOTOR 1 RN24076-9 <
97 THREAD ROD M16 0.5’ VL2402 <
98 MOUNTING PLATE  HDF 1 RN24079-11 <
99 NUT HEX M16 2 VH1531 <
100 HHCS 5/16-18 X 1" GRADE 5 2 VH12HH1 <
101 FLAT WASHER 5/16” 4 VH32H1 <
102 LOCK WASHER 5/16” 2 VH35H1 <
103 NUT HEX 5/16-18 ZINC PLATED 2 VH15H1 <







n 1972, Gene Keaton started H&K Pump in Dallas, Texas. After serving with distinction in the World War II, Gene decided he wanted to pursue a career above the stratosphere and help the USA in the space race against the Russians. For the next 30 years of his life, Gene worked as a tool design engineer in the aerospace industry at NASA, General Dynamics, and McDonnell Douglas.


There wasn’t a tool that Gene couldn’t design or a project too difficult for this NASA engineer. He worked on the Mercury project and the Apollo projects in the early 1960s up until 1972. In 1973, Gene planted his roots in the Dallas-Fort Worth area and opened his own air compressor company together with his wife, Charlotte, and their son, Richard.






ITEM NO. DESCRIPTION QTY. RSB40 RSB50
1 CONTROL BACK PANEL
2 STARTER WITH INTERCHANGEABLE HEATERS SEE TABLE 2
3 STARTER SIZE “A” WITH INTERCHANGABLE HEATERS 1 RN18959 <
4 FUSE BLOCK - 30A, 600V 1 RN18314-1 <
5 TERMINAL BLOCK 6 1330042 <
6 TERMINAL BLOCK END STOP 1 1330043 <
7 TRANSFOMER, 150VA,FUSED, 200/208/230/460-120V
8 FUSE, TRANSFORMER, PRIMARY SEE TABLE 2
9 FUSE, TRANSFORMER, SECONDARY
10 RELAY, 4 POLE, 120V, DPDT 1 1330062 <
11 SOCKET 1 1330049 <
12 TIMER, 60 MIN., PLUG-IN 1 1330026 <
13 PUSH BUTTON START SWITCH 1 RN18116-M22 <
14 PUSH BUTTON STOP SWITCH (RED) 1 RN18118-M22 <
15 2 POSITION SELECTOR SWITCH (CONST/AUTO) 1 RN18104-9M22 <
16 2 POSITION SELECTOR SWITCH (LOAD/UNLOAD) 1 RN18104-7M22 <
17 HOURMETER 1 1330048 <
18 AMBER LIGHT (STAND BY) 1 RN18218-M22 <
19 RED LIGHT (STOP) 1 RN18217-M22 <
20 GREEN LIGHT (POWER ON) 1 RN18219-M22 <
21 TEMPERATURE GAUGE 1 RN18692 <
22 HEATER - MAIN (NOT SHOWN)
23 HEATER - FAN (NOT SHOWN) SEE TABLE 2
24 FUSE, FAN (NOT SHOWN)
25 AUX  CONTACTOR 1 VSB886 <
26 CONTACTOR  NO/NC (Y-DELTA ONLY) 1 N/A <
27 ANTI-START PRESSURE SWITCH 1 RN18134 <
28 LUG, GROUNDING 2 VE779 <
29 ENCLOSURE 1 1330058 <



ROTARY SCREW AIR COMPRESSOR



Curtis (rotary screw air compressor) is the number one brand in the industry when it comes to reliability and functionality. FS-Curtis compressors are engineered to be the most efficient compressor, saving you thousands of dollars every year on energy bills. Bar none, they are some of the most quiet compressors ever built.


The NX series rotary screw air compressors are housed in a space-saving design and built for continuous, quiet operation delivering a steady airflow with stable air pressure. The result is outstanding air quality with minimal oil carryover, giving you the performance you need backed by the durability you want.


- The NXB04 (5HP tank mounted) is only: $5,312

- The NXB06 (7.5HP tank mounted) is only: $6,227

- The NXB08 (10HP tank mounted) is only: $7,326

- The NXB11 (15HP tank mounted) is only: $9,115






NO. DESCRIPTION QTY. RSB40-50
1 CONTROL PANEL ASSEMBLY
2 STARTER WITH INTERCHANGEABLE HEATERS (MAIN MOTOR) SEE TABLE 3
3 STARTER WITH INTERCHANGABLE HEATERS (FAN)
4 FUSE BLOCK - 30A, 600V 1 RN18314-1
5 TERMINAL BLOCK 26 1330042
6 END STOP 2 1330043
7 TRANSFORMER
8 FUSE, TRANSFORMER, PRIMARY SEE TABLE 2
9 FUSE, TRANSFORMER, SECONDARY
10 RELAY, 4 POLE, 120V, DPDT 2 1330062
11 SOCKET 2 1330049
12 TIMER, 60 MIN., PLUG-IN 1 1330026
13 TIMER, 30 SEC., PLUG-IN 1 1330031
14 ENCLOSURE 1 RN18059
15 PUSH BUTTON START SWITCH (GREEN) 1 RN18116-M22
16 PUSH BUTTON STOP SWITCH (RED) 1 RN18118-M22
17 2 POSITION SELECTOR SWITCH (CONST/AUTO) 1 RN18104-9M22
18 2 POSITION SELECTOR SWITCH (LOAD/UNLOAD) 1 RN18104-7M22
19 HOURMETER 1 1330048
20 AMBER LIGHT (STAND BY) 1 RN18218-M22
21 RED LIGHT (STOP) 1 RN18217-M22
22 GREEN LIGHT (POWER ON) 1 RN18219-M22
23 TEMPERATURE GAUGE 1 RN18683
24 HEATER - MAIN (NOT SHOWN)
25 HEATER - FAN (NOT SHOWN) SEE TABLE 3
26 FUSE, FAN (NOT SHOWN)
27 VALVE, SOLENOID 1 RN18422
28 SWITCH, PRESSURE 1 RN18133-2
29 SWITCH, ANTI-START PRESSURE 1 RN18134
30 LUG, GROUNDING 2 VE779
31 CONTACTOR REV. M1-S/M1-S WITH NO/NC SEE TABLE 3
32 NIPPLE 1/4”NPT X CLOSE 1 VA13BAV
WIRING DIAGRAM FOR Y-DELTA CAB1665A




ITEM 200 VOLT 230 VOLT 460 VOLT 575 VOLT
DESCRIPTION QTY.
NO.
RSB40 1 CONTROL PANEL 1 1330001 1330001 1330000 1330078
RSB40 2 SIZE “K” STARTER 1 N/A N/A RN18960 <
RSB40 2 SIZE “N” STARTER 1 RN18963 < N/A N/A
RSB40 2 SIZE “S” STARTER 1 N/A N/A N/A N/A
RSB40 3 SIZE “A” STARTER (FAN) AIR COOLED ONLY 1 RN18959 < < <
RSB40 3 SIZE “B” STARTER (FAN) AIR COOLED ONLY 1 N/A N/A N/A N/A
RSB40 7 TRANSFORMER, 150VA,FUSED, 120V 1 1330075 < < 1330055
RSB40 7 TRANSFORMER, 250VA,FUSED, 120V 1 N/A N/A N/A N/A
RSB40 8 FUSE, TRANSFORMER, PRIMARY 2 RN18345-1 < < <
RSB40 9 FUSE, TRANSFORMER, SECONDARY 1 RN18351 < < <
RSB40 24 HEATER - MAIN (NOT SHOWN) 1 RN18990 RN18989 RN18982 RN18981
RSB40 25 HEATER - FAN (NOT SHOWN) AIR COOLED ONLY 1 RN18975 RN18974 RN18972 RN18971
RSB40 26 FUSE, FAN (NOT SHOWN) AIR COOLED ONLY 3 RN18317-1 RN18317 RN18316-1 VE396
RSB50 1 CONTROL PANEL 1 1330061 1330001 1330000 1330078
RSB50 2 SIZE “K” STARTER 1 N/A N/A RN18960 <
RSB50 2 SIZE “N” STARTER 1 N/A RN18963 N/A N/A
RSB50 2 SIZE “S” STARTER 1 RN18860 N/A N/A N/A
RSB50 3 SIZE “A” STARTER(FAN) AIR COOLED ONLY 1 N/A RN18959 < <
RSB50 3 SIZE “B” STARTER(FAN) AIR COOLED ONLY 1 RN18950 N/A N/A N/A
RSB50 7 TRANSFORMER, 150VA,FUSED, 120V 1 N/A 1330075 < <
RSB50 7 TRANSFORMER, 250VA,FUSED, 120V 1 1330076 N/A N/A N/A
RSB50 8 FUSE, TRANSFORMER, PRIMARY 2 VE385 RN18345-1 < <
RSB50 9 FUSE, TRANSFORMER, SECONDARY 1 RN18354 RN18351 < <
RSB50 24 HEATER - MAIN (NOT SHOWN) 1 RN18972 RN18990 RN18983 RN18982
RSB50 25 HEATER - FAN (NOT SHOWN) AIR COOLED ONLY 1 RN18976 RN18975 RN18973 RN18972
RSB50 26 FUSE, FAN(NOT SHOWN) AIR COOLED ONLY 3 VE399 RN18317-1 RN18316-2 RN08316-1



RSB40-50 VOLT VOLT VOLT VOLT
RSB40-50 CONTROL PANEL ASSEMBLY 1 1330089 1330088 1330088 1330088
RSB40-50 SIZE “N” STARTER 1 RN18963 N/A N/A N/A
RSB40-50 SIZE “K” STARTER 1 N/A RN18960 RN18960 RN18960
RSB40-50 CONTACTOR REV. M1-S/M1-S WITH 1 RN18540 N/A N/A N/A
RSB40-50 NO/NC, SIZE “N”
RSB40-50 SIZE “K” 1 N/A RN18536 RN18536 RN18536
RSB40-50 SIZE “E” STARTER (FAN) 1 RN18965 RN18965 RN18965 RN18965
RSB40-50
RSB40-50 TRANSFORMER, 250VA, FUSED, 120V 1 1330076 1330054 1330054 1330054
RSB40-50 FUSE, TRANSFORMER, PRIMARY 2 VE334 VE334 VE334 VE334
RSB40-50 FUSE, TRANSFORMER, SECONDARY 1 RN18393 RN18393 RN18393 RN18393
RSB40-50 HEATER - MAIN 1 RN18988 RN18983 RN18981 RN18980
RSB40-50 HEATER - FAN 1 RN18975 RN18975 RN18973 RN18972
RSB40-50 FUSE, FAN 3 VE399 VE399 RN18316-3 RN18316-2









SCREW,5/16-18 X 3/4" GRADE 5 1 VH12HF1 <
LOCKWASHER-KANTLINK-SPLIT 1 VH35H <
WASHER-FLAT-CUT 5/16" 1 VH32H <
MOUNTS-VIBRATION 1 RN60255 <
BUSHING 2 X 1 1/2" 1 VA12JHV <
NIPPLE 1 1/2 X CLOSE 1 VA13HBV <
VALVE-BALL 1 1/2" 1 RN42240 <
ELBOW, 1 1/4" X 1 1/4", 90 DEGREE MALE (LONG) 2 RN60089 <
BUSHING, 2"NPT X 1 1/4"NPT  GALV 1 VA12JGG <
ASME TANK 200 GAL GRASS 1 OFD247A <
BUSHING 1" X 1/4" 1 VA12FBV <
PLUG-SQUARE HEAD-STEEL 1/4" 1 VA01BA <
PLUG-SQUARE HEAD-CORED 1 1/4" 1 VA02GR <
PLUG- SQUARE HEAD-STEEL 1/2" 2 VA01DR <
BUSHING 3/4 X 1/2" 1 VA12EDV <
NIPPLE-CLOSE 1/2" 1 VA13DAV <
TEE 1/2"NPT 1 VA10DF <
BUSHING REDUCER 1/2" X 1/4" HEX. HEAD 1 VA12DBV <
ELBOW-STREET 1/4" 1 VA08BV <
NIPPLE 1/4 X 6" 1 VA13BLV <
GAUGE,AIR 2"DIAL,1/4"NPT  BACK MOUNT CONN., 0-300 PSI 2 VA302 <
ELBOW-90 DEGREE 1/4" 1 VA06BG <
TEE 1/4" 150# M.I. 1 VA10BQ <
CONNECTOR 1/4" NPT X 1/4" OD. 1 VAA703 <
TUBING-NYLON 1 VA1626 <
HOSE ASSY 1 RN60144 <
DRAIN COCK 1/4" 1 VV514 <
BALL VALVE-3/8", 200#  PRESSURE 1 VV539 <
TEE-BLACK 3/8" 1 VA10CF <
NIPPLE-GALV. 3/8 X 6" 1 VA13CCE <
UNION-GROUND JOINT-GALV. 3/8" 1 VAC806 <
NIPPLE-GALV. 3/8 X 3" 2 VA13CEB <
BUSHING 3/8 X 1/4, GALV 2 VA12CBA <
NIPPLE-GALV.-CLOSE 3/8" 1 VA13CAB <
DRAIN COCK 1/4" 1 VV514 <
LOCK WASHER ZINC PLATED 1/4" MEDIUM 4 VH35F1 <
NUT-FINISHED-HEX 1/4-20 ZINC PLATED 2 VH15F1 <
WASHER FLAT CUT 1/4" 4 VH32F1 <
HHCS 1/4-20 X 3/4" LONG ZINC PLATED 2 VH12FF1 <
BRACE-AUTO. DRAIN PIPING 1 OFE950 <
DRAIN, AUTO-TIMER,1/60/115V 300PSI 7/16" ORIFICE, 3/8" 1 VA536-1 <
U BOLT #401 1 VH2202 <
BUSHING-GALV. 1/2 X 3/8" 1 VA12DCQ <
CONDENSATE AUTOMATIC DRAIN  #508 3/8"NPT 175 PSIG 1 VAA511 <
BALL VALVE-3/8", 200#  PRESSURE 1 VV539 <
TEE 3/8 PIPE GLV 1 VA10CF <
UNION-GROUND JOINT-GALV. 3/8" 1 VAC806 <
NIPPLE-GALV.-CLOSE 3/8" 1 VA13CAB <
NIPPLE-GALV. 3/8 X 6" 1 VA13CCE <
NIPPLE-GALV. 3/8 X 3" 2 VA13CEB <
DRAIN COCK 1/4" 1 VV514 <
HHCS 1/4-20 X 3/4" LONG ZINC PLATED 2 VH12FF1 <
NUT-FINISHED-HEX 1/4-20 ZINC PLATED 2 VH15F1 <
LOCK WASHER ZINC PLATED 1/4" MEDIUM 4 VH35F1 <
WASHER FLAT CUT 1/4" 4 VH32F1 <
BUSHING 3/8 X 1/4", GALV 2 VA12CBA <
BRACE-AUTO. DRAIN PIPING 1 OFE950 <
U BOLT #401 1 VH2202 <
BUSHING-GALV. 1/2 X 3/8" 1 VA12DCQ <
TUBING-NYLON 1 VA1601 <



AIR COMPRESSOR REVIEWS



Whether you want to buy a new air compressor for your business or you need someone to fix the one you currently have, H&K Pump is here to assist you. Trust us to provide you with first-rate air compressor repair and maintenance services and offer only high-quality parts from trusted brands.

--------------------------------------------------------------------------------------------------------------------------------

Terrell, Texas (April 2014): "H&K installed an air compressor in my manufacturing plant over 26 years ago. I just recently bought another one from them last week. Great work ethics and a great price."

Fort Worth, Texas (Feb. 2015) "My father started our stone cutting business over 30 years ago and he remembered Gene Keaton and H&K Pump. They installed our first compressor and it virtually worked for over 30 years with no problems. We are expanding our facility and needed a larger unit with more CFM's and Gene Keaton still remembered our company. Now that is excellent customer service."

Dallas, Texas (Dec. 2016): "I have been using H&K Pump for over 30 years and have found them to be the top experts in their field. If I ever have any issues, they are there to help."

Plano, Texas (March 2016): "Fast reliable service and at a great price."

Waco, Texas (Jan. 2017): "These guys are the best. We have a slew of dry cleaning stores and H&K always deliver top service."

Dallas, Texas: (July 2017) "I used another company before I found H&K Pump. Everyone told me to just call H&K as they were the best in the industry. They came out to my business and really explained what was wrong with my existing air compressor and why it wasn't doing what I needed it to do. I bought a new heavy duty air compressor and a new refrigerated air dryer from them. They installed it three days later and it is awesome. Thank you H&K."

Dallas, Texas:(March 2018) "We use H&K Pump exclusively for all our sales and service and have been using them for over 30 years now. We have a lot of cement facilities and these guys just know their products and repairs."

Fort Worth, Texas: (November 2018) "This is the third rotary screw compressor that our company has purchased from H&K over the past 5 years. Got to tell you, that Curtis machine is awesome and so are the guys at H&K Pump. They are the ONLY company that I would trust when it comes to air compressors."

Sherman, Texas: (January 2019). "We have a automotive collision repair shop here in Sherman, Texas. I was having problems with the air compressor that I bought from one of their competitors over 2 years ago. No one knew how to fix our rotary until Richard Keaton from H&K Pump came out to work on it. He fixed our machine in less than 30 minutes and didn't even charge us anything. Because of their excellent customer service and knowledge, we just purchase two new compressors from these folks. Thank you H&K pump."

Forney, Texas.  (March 2019)  We are a marble and granite cutting facility.  I have used other compressor companies in the past.  I have gotten terrible service from IR and Atlas Copco.  H&K came out the same day I called them and fixed my machine on the spot.  These guys know what they are doing and understand customer service!!

Dallas, Texas  (November 2019)  We are a pallet company.  Needed a new compressor for our facility.  I called my friend who owns a large pallet company in Hutchins, Texas.  They strongly recommended H&K.  Great price and really friendly people to work with.

Sherman, Texas: (April 2020).  I found H&K on the internet.  I needed a new compressor for my facility.  I got the new Curtis Rotary Screw compressor (around a 15HP) and boy is it quiet.  It doesn't spook out the cows when the machine clicks on.  The technicians are very knowledgeable of the products in the market and were very respective of my time limits.  Good job H&K air compressors.

Houston, Texas: (May, 2020)  This is the best shop for compressor work in Texas. Eric and his staff are professional and quick. I have a shop in Houston and I was willing to spend the money on the cross state work because their experience is matched. I highly recommend for all your pump and compressor needs.

Waxahachie, Texas. (May, 2020)   I own a small custom repair shop in Texas and needed some parts for my compressor.  These guys were fantastic.  I was able to get the parts that day and installed.  They saved me a ton of money and time.

Dallas, Texas. (June, 2020)  I just needed to get my IR air compressor serviced. I called today and they said they would be out tomorrow. Actually showed up at the end of the day today and took care of it very quickly. My first experience was very good and technician was friendly! I will call them again

Texas. (August, 2020)  (Eagle Transmission)  My shop compressor shut down about 10:30 on a work day. I was calling around looking for someone who could get to it quick. H&K had a full day scheduled, but they made time to stop by between calls. They spent 15-20 minutes diagnosing it, but did not have the part to fix it. Because of their busy schedule, they would not be able to get the part till the next day. Since the problem was going to be easy to fix, ( now that I knew what was wrong) I was able to get the part and install it myself. My shop was back in production by 1:30 Their attitude and service could not be better Thanks Eric

--------------------------------------------------------------------------------------------------------------------------------

At H&K Pump, we sell only the best equipment in the market today. If you are looking for a new Rotary Screw Air Compressor or a Reciprocating Air Compressor, give us a call at: 214-428-2868. We service air compressors and we repair and rebuild air compressor pumps. When you want the best air compressor service, call H&K Pump first.

For questions, feel free to contact us in Dallas, Texas. We look forward to hearing from you!





































































air compressor service
www.hkaircompressors.com











air compressor service
www.hkaircompressors.com





air compressor service
www.hkaircompressors.com





air compressor service
www.hkaircompressors.com




air compressor service
www.hkaircompressors.com


AIR COMPRESSOR SERVICE NEAR ME






AIR COMPRESSORS







AIR COMPRESSOR SERVICE NEAR ME




air compressor service
www.hkaircompressors.com

AIR COMPRESSOR SERVICE NEAR ME







AIR COMPRESSOR REPAIR NEAR ME






AIR COMPRESSOR REPAIR NEAR ME





air compressor service
www.hkaircompressors.com
















AIR COMPRESSOR INSTALLATION








COMPRESSOR LINES









AIR COMPRESSOR SERVICE NEAR ME







AIR COMPRESSOR REPAIR NEAR ME



D75 COMPRESSOR PARTS

PART NO.

DESCRIPTION

46842416

MAINTENANCE KIT, 2000 HOUR DOOSAN

46842421

FLUID ANALYSIS, KIT

46849989

MAINTENANCE KIT, 4000 HOUR DOOSAN

46839841

ELEMENT, SEPARATOR

46839840

GASKET, SEPARATOR ELEMENT

46839848

ELEMENT, OIL FILTER

46839859

ELEMENT, AIR FILTER

46842421

FLUID ANALYSIS, KIT

46849993

MAINTENANCE KIT, 8000 HOUR DOOSAN

46839841

ELEMENT, SEPARATOR

46839840

GASKET, SEPARATOR ELEMENT

46839848

ELEMENT, OIL FILTER

46839859

ELEMENT, AIR FILTER

46839847

SERVICE KIT, VENT INLET

46839844

WINDOW, OIL SCAVENGE

46839067

SERVICE KIT, BYPASS OIL

46842421

FLUID ANALYSIS, KIT

46849994

MAINTENANCE KIT, 16000 HOUR DOOSAN

46839841

ELEMENT, SEPARATOR

46839840

GASKET, SEPARATOR ELEMENT

46839848

ELEMENT, OIL FILTER

46839859

ELEMENT, AIR FILTER

46839847

SERVICE KIT, VENT INLET

46839844

WINDOW, OIL SCAVENGE

46839067

SERVICE KIT, BYPASS OIL

46839838

SERVICE KIT, MPCV

46842421

FLUID ANALYSIS, KIT

46850169

MAINTENANCE KIT, 24000 HOUR D75

46837831

VALVE, SAFETY

46839067

VALVE ASSEMBLY, VENT INLET

46839069

CYLINDER, INLET VALVE

46839841

ELEMENT, SEPARATOR

46839844

WINDOW, OIL SCAVENGE

46839847

SERVICE KIT, BYPASS OIL

46839848

ELEMENT, OIL FILTER

46839859

ELEMENT, AIR FILTER

46842421

ANALYSIS KIT, FLUID

PART NO.

DESCRIPTION



Other Recommended Spares (Continued):



Other Recommended Spares:

46839848

ELEMENT, OIL FILTER

46839859

ELEMENT, AIR FILTER

46839845

BYPASS VALVE ASSEMBLY

46839827

COUPLING, DRIVE

46839847

BYPASS V/V INSERT KIT

46837825

WINDOW, OIL SIGHT LEVEL

46837824

GASKET, SIGHT WINDOW

46839842

PLUG, SEPARATOR TANK OIL FILL

46839843

O-RING, SEPARATOR TANK OIL FILL

46839844

WINDOW, OIL SCAVENGE

46837832

GAUGE, PRESSURE

46839838

SERVICE KIT, MPCV

46839396

FILTER, CONTROL BOX

46839065

VALVE ASSEMBLY, INLET

46839834

GASKET, INLET VALVE

46839067

VENTING VALVE ASSEMBLY

46839068

SERVICE KIT, VENT INLET

46839861

HOSE, AIR FILTER INLET

46837835

TEMP SENSOR CONNECTOR,

46838895

SENSOR, TEMPERATURE

46838896

TRANSDUCER, PRESSURE

46838885

SWITCH ASSEMBLY, E-STOP

46839844

WINDOW, OIL SCAVENGE

46839836

COVER ASSEMBLY, SEPARATOR TANK MPCV

46839838

SERVICE KIT, MPCV

46839832

MOUNT, ISOLATION

46838880

CONTACTOR, MAGNETIC

46839376

CONTACTOR, , MAGNETIC

46840370

CONTACTOR, , MAGNETIC

46840407

CONTACTOR, , MAGNETIC

46844027

SOLENOID VALVE, INLET

46838888

RELAY, PHASE MONITORING

46838886

NOISE FILTER

46837831

VALVE, SAFETY

46838887

SPARK KILLER

46838884

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840374

CIRCUIT BREAKER

46840375

CIRCUIT BREAKER

46844109

CIRCUIT BREAKER

46844107

HOSE KIT, CONTROL



D100 HP COMPRESSOR PARTS

PART NO.

DESCRIPTION

46842416

MAINTENANCE KIT, 2000 HOUR DOOSAN

46842421

FLUID ANALYSIS, KIT

46850170

MAINTENANCE KIT, 4000 HOUR DOOSAN

46839841

ELEMENT, SEPARATOR

46839840

GASKET, SEPARATOR ELEMENT

46839848

ELEMENT, OIL FILTER

46840398

ELEMENT, AIR FILTER

46842421

FLUID ANALYSIS, KIT

46850171

MAINTENANCE KIT, 8000 HOUR DOOSAN

46839841

ELEMENT, SEPARATOR

46839840

GASKET, SEPARATOR ELEMENT

46839848

ELEMENT, OIL FILTER

46840398

ELEMENT, AIR FILTER

46839847

SERVICE KIT, BYPASS OIL

46839844

WINDOW, OIL SCAVENGE

46840393

VALVE ASSEMBLY, VENT INLET

46842421

FLUID ANALYSIS, KIT

46850174

MAINTENANCE KIT, 16000 HOUR DOOSAN

46839841

ELEMENT, SEPARATOR

46839840

GASKET, SEPARATOR ELEMENT

46839848

ELEMENT, OIL FILTER

46840398

ELEMENT, AIR FILTER

46840393

VALVE ASSEMBLY, VENT INLET

46839838

SERVICE KIT, MPCV

46842421

FLUID ANALYSIS, KIT

46850175

MAINTENANCE KIT, 24000 HOUR D100

46837831

VALVE, SAFETY,

46839069

CYLINDER, INLET VALVE,

46839841

ELEMENT, SEPARATOR,

46839844

WINDOW, OIL SCAVENGE,

46839847

SERVICE KIT, BYPASS OIL,

46839848

ELEMENT, OIL FILTER,

46840393

VALVE ASSEMBLY, VENT INLET,

46840398

ELEMENT, AIR FILTER,

46842421

ANALYSIS KIT, FLUID,

PART NO.

DESCRIPTION



Other Recommended Spares:

46839848

ELEMENT, OIL FILTER,

46840398

ELEMENT, AIR FILTER,

46839845

VALVE ASSEMBLY, BYPASS OIL,

46840388

COUPLING, DRIVE,

46839847

SERVICE KIT, BYPASS OIL,

46837824

WINDOW, OIL SIGHT LEVEL,

46837825

GASKET, SIGHT WINDOW,

46839842

PLUG, SEPARATOR TANK OIL FILL,

46839844

WINDOW, OIL SCAVENGE,

46837832

GAUGE, PRESSURE,

46839838

SERVICE KIT, MPCV,



Other Recommended Spares:

46839396

FILTER, CONTROL BOX

46840391

VALVE ASSEMBLY, INLET

46839834

GASKET, INLET VALVE FLANGE

46840393

VALVE ASSEMBLY, VENT INLET

46839068

SERVICE KIT, VENT INLET

46840400

HOSE, AIR FILTER INLET

46838895

SENSOR, TEMPERATURE

46838896

TRANSDUCER, PRESSURE

46838885

SWITCH ASSEMBLY, E-STOP

46839844

WINDOW, OIL SCAVENGE

46839836

COVER ASSEMBLY, SEPARATOR TANK MPCV

46839838

SERVICE KIT, MPCV

46839832

MOUNT, ISOLATION

46838880

CONTACTOR, MAGNETIC

46840407

CONTACTOR, MAGNETIC

46840408

CONTACTOR, MAGNETIC

46840409

CONTACTOR, MAGNETIC

46844027

SOLENOID VALVE, INLET

46838888

RELAY, PHASE MONITORING

46838886

NOISE FILTER

46837831

VALVE, SAFETY

46838887

SPARK KILLER

46840373

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840367

HOSE KIT, CONTROL

D75

PART NO.

DESCRIPTION

46839825

FRAME, STANDARD

46839831

MOTOR, MARATHON 55KW 230/460V 60HZ

46839826

AIREND

46839065

VALVE ASSEMBLY, INLET

46844106

O-RING

46839833

FLANGE, INLET VALVE

46839834

GASKET, INLET VALVE FLANGE

46839829

COUPLING, HOUSING

46839827

COUPLING, DRIVE

46839828

ELEMENT, COUPLING

46839832

MOUNT, ISOLATION

46837815

MOUNT, ISOLATION

46839918

WASHER

46839830

GUARD, COUPLING

46844105

SEAL KIT, AIREND LIP

PART NO.

DESCRIPTION

46839065

VALVE ASSEMBLY, INLET

46839067

VALVE ASSEMBLY, VENT INLET

46839068

SERVICE KIT, VENT INLET

46839069

CYLINDER, INLET VALVE

46844027

SOLENOID VALVE, INLET



D75

PART NO.

DESCRIPTION

46839835

TANK, SEPARATOR

46839841

ELEMENT, SEPARATOR

46839840

GASKET, SEPARATOR ELEMENT

46839848

ELEMENT, OIL FILTER

46839845

VALVE ASSEMBLY, BYPASS OIL

46839091

ADAPTER

46839843

O-RING

46839842

PLUG, SEPARATOR TANK OIL FILL

46837824

GASKET, SIGHT WINDOW

46837825

WINDOW, OIL SIGHT LEVEL

46839844

WINDOW, OIL SCAVENGE

46837836

ELBOW

46839092

TUBE, OIL SCAVENGE

46837835

CONNECTOR

46837831

VALVE, SAFETY

46837832

GAUGE, PRESSURE

46837833

VALVE, BALL OIL DRAIN

ITEM

PART NO.

PART NO.

DESCRIPTION

46839838

SERVICE KIT, MPCV

75HP Oil Bypass Valve Assembly

PART NO.

DESCRIPTION

46839845

VALVE ASSEMBLY, BYPASS OIL

46839846

CASTING, BYPASS OIL

46839847

SERVICE KIT, BYPASS OIL

PART NO.

DESCRIPTION

46839851

SHROUD, FAN

46839849

COOLER, COMBINATION

46839850

BRACKET, COOLER MOUNTING

46839853

PANEL, COOLER CLEAN OUT

46839852

BRACKET, FAN SHROUD

46839079

FAN ASSEMBLY

46839235

ELBOW

46839234

ADAPTER, HEX LONG

75HP Inlet Filter, Oil Piping, Air Piping Installation

PART NO.

DESCRIPTION

46839869

HOSE, OIL SUPPLY

46839870

ADAPTER, ELBOW

46839874

ADAPTER

46839868

PIPE, OIL SUPPLY

46839855

O-RING

46839854

PIPE, AIREND DISCHARGE

46839856

GASKET

46839863

TUBE, OIL COOLER OUT

46839862

TUBE, OIL COOLER IN

46839864

ELBOW

46839871

PIPE, SEP TANK TO AFTERCOOLER

46839872

O-RING

46839873

ADAPTER

46839865

HOSE, OIL RETURN

46839866

HOSE, VENT LINE

46839867

HOSE, INLET VALVE CONTROL LINE

46839861

HOSE, AIR FILTER INLET

46843358

CLAMP, HOSE

46839858

HOUSING, AIR FILTER

46839859

ELEMENT, AIR FILTER

46839860

BRACKET, AIR FILTER

46839857

FILTER ASSEMBLY, INLET

46838709

VALVE, BALL

PART NO.

DESCRIPTION

46839886

POST, FRONT LEFT CORNER

46840445

POST, FRONT MIDDLE

46839888

POST, FRONT RIGHT CORNER

46839889

POST, REAR LEFT CORNER

46839890

POST, REAR MIDDLE

46839891

POST, REAR RIGHT CORNER

46839892

POST, FRONT CONTROL BOX

46839893

ANGLE, LEFT SIDE

46839894

ANGLE, RIGHT SIDE

46839895

CHANNEL, FRONT

46839896

ANGLE, FRONT

46839897

ANGLE, REAR

46839900

DOOR, LEFT

46839902

DOOR, MIDDLE

46839901

DOOR, CONTROL PANEL

46839906

PANEL, REAR

46839903

PANEL, SIDE LEFT

46839904

PANEL, SIDE RIGHT UPPER

46839905

PANEL, SIDE RIGHT LOWER

46839907

PANEL, ROOF LEFT

46839908

PANEL, ROOF AIR OUTLET

46839899

BAFFLE, INLET PARTITION

46839898

BAFFLE, INLET

46839910

PANEL, COOLER CONTROL LEFT

46839911

PANEL, COOLER CONTROL RIGHT

46838737

HINGE, DOOR

46839273

HINGE, DOOR

46838738

LATCH, DOOR

46843360

BRACKET, CONTROLLER WIRING

46839396

FILTER, CONTROL BOX

75HP Electrical, Control Box Installation(700080KIAFJ10 and Prior)

PART NO.

DESCRIPTION

46839909 46839914

ENCLOSURE, CONTROL BOX PANEL, ELECTRICAL MOUNTING

PART NO.

DESCRIPTION

46839909 46847255

ENCLOSURE, CONTROL BOX PANEL, ELECTRICAL MOUNTING





75HP Electrical, Control Panel Assembly (700080KIAFJ10 and Prior)

PART NO.

DESCRIPTION

46847255

PANEL, ELECTRICAL MOUNTING

46840368

CONTROLLER, DISPLAY/CONTROLLER

46840407

CONTACTOR, MAGNETIC

46840370

CONTACTOR, MAGNETIC

46839376

CONTACTOR, MAGNETIC

46838880

CONTACTOR, MAGNETIC

46844108

BREAKER, OVER CURRENT PROTECTION

46839251

BREAKER, OVER CURRENT PROTECTION

46844109

CIRCUIT BREAKER

46844109

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840374

CIRCUIT BREAKER

46840375

CIRCUIT BREAKER

46838884

CIRCUIT BREAKER

46838885

SWITCH ASSEMBLY, E-STOP

46838886

NOISE FILTER

46840376

SWITCH, POWER SUPPLY

46838887

SPARK KILLER

46838888

RELAY, PHASE MONITORING

46839377

TERMINAL BLOCK

46840377

TERMINAL BLOCK

46840378

TERMINAL BLOCK

46839378

TERMINAL BLOCK

46843190

TRANSFORMER

46838896

TRANSDUCER, PRESSURE

46838895

SENSOR, TEMPERATURE

46839379

GROUND BAR

PART NO.

DESCRIPTION

46847255

PANEL, ELECTRICAL MOUNTING

46844109

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840374

CIRCUIT BREAKER

46843188

CIRCUIT BREAKER

46843189

CIRCUIT BREAKER

46847256

CONTACTOR, MAGNETIC

46839376

CONTACTOR, MAGNETIC

46838880

CONTACTOR, MAGNETIC

46843186

BREAKER, OVER CURRENT PROTECTION

46839251

BREAKER, OVER CURRENT PROTECTION

46839379

GROUND BAR

46838885

SWITCH ASSEMBLY, E-STOP

46840368

CONTROLLER, DISPLAY/CONTROLLER

46838886

NOISE FILTER

46838896

TRANSDUCER, PRESSURE

46840376

SWITCH, POWER SUPPLY

46838887

SPARK KILLER

46838888

RELAY, PHASE MONITORING

46838895

SENSOR, TEMPERATURE

46839377

TERMINAL BLOCK

46839378

TERMINAL BLOCK

46840377

TERMINAL BLOCK

46840378

TERMINAL BLOCK

46843190

TRANSFORMER

D100 HP ROTARY SCREW FOR BOBCAT AND DOOSAN

PART NO.

DESCRIPTION

46840386

FRAME, STANDARD

46840390

MOTOR, MARATHON 75KW 230/460V 60HZ

46840387

AIREND

46840389

COUPLING, HOUSING

46840388

COUPLING, DRIVE

46839828

ELEMENT, COUPLING

46840391

VALVE ASSEMBLY, INLET

46839834

GASKET, INLET VALVE FLANGE

46839832

MOUNT, ISOLATION

46837815

MOUNT, ISOLATION

46839918

WASHER

46839830

GUARD, COUPLING

46844138

SEAL KIT, AIREND LIP

100HP Inlet Valve Assembly

PART NO.

DESCRIPTION

46840391

VALVE ASSEMBLY, INLET

46840393

VALVE ASSEMBLY, VENT INLET

46839068

SERVICE KIT, VENT INLET

46839069

CYLINDER, INLET VALVE

46844027

SOLENOID VALVE, INLET

D100 HP ROTARY SCREW

PART NO.

DESCRIPTION

46840391

VALVE ASSEMBLY, INLET

46840393

VALVE ASSEMBLY, VENT INLET

46839068

SERVICE KIT, VENT INLET

46839069

CYLINDER, INLET VALVE

46844027

SOLENOID VALVE, INLET

100HP Oil Separator Tank Assembly

PART NO.

DESCRIPTION

46839835

TANK, SEPARATOR

46839841

ELEMENT, SEPARATOR

46839840

GASKET, SEPARATOR ELEMENT

46839848

ELEMENT, OIL FILTER

46839845

VALVE ASSEMBLY, BYPASS OIL

46839091

ADAPTER

46839843

O-RING

46839842

PLUG, SEPARATOR TANK OIL FILL

46837824

GASKET, SIGHT WINDOW

46837825

WINDOW, OIL SIGHT LEVEL

46839844

WINDOW, OIL SCAVENGE

46837836

ELBOW

46839092

TUBE, OIL SCAVENGE

46837835

CONNECTOR

46837831

VALVE, SAFETY

46837832

GAUGE, PRESSURE

46837833

VALVE, BALL OIL DRAIN

PART NO.

DESCRIPTION

46839838

SERVICE KIT, MPCV

100HP Oil Bypass Valve Assembly

PART NO.

DESCRIPTION

46839845

VALVE ASSEMBLY, BYPASS OIL

46839846

CASTING, BYPASS OIL

46839847

SERVICE KIT, BYPASS OIL

PART NO.

DESCRIPTION

46839851

SHROUD, FAN

46839849

COOLER, COMBINATION

46840394

BRACKET, COOLER MOUNTING

46839853

PANEL, COOLER CLEAN OUT

46839852

BRACKET, FAN SHROUD

46839079

FAN ASSEMBLY

46839235

ELBOW

46839234

ADAPTER, HEX LONG

100HP Inlet Filter, Oil Piping, Air Piping Installation

PART NO.

DESCRIPTION

46839869

HOSE, OIL SUPPLY

46839870

ADAPTER, ELBOW

46839874

ADAPTER

46840401

PIPE, OIL SUPPLY

46839855

O-RING

46839854

PIPE, AIREND DISCHARGE

46839856

GASKET

46839863

TUBE, OIL COOLER OUT

46839862

TUBE, OIL COOLER IN

46839864

ELBOW

46839871

PIPE, SEP TANK TO AFTERCOOLER

46839872

O-RING

46839873

ADAPTER

46844141

HOSE, OIL RETURN

46839244

HOSE, VENT LINE

46839245

HOSE, INLET VALVE CONTROL LINE

46840400

HOSE, AIR FILTER INLET

46844139

CLAMP, HOSE

46844140

CLAMP, HOSE

46840397

HOUSING, AIR FILTER

46840398

ELEMENT, AIR FILTER

46840399

BRACKET, AIR FILTER

46840396

FILTER ASSEMBLY, INLET

46838709

VALVE, BALL

PART NO.

DESCRIPTION

46839909 46839914

ENCLOSURE, CONTROL BOX PANEL, ELECTRICAL MOUNTING





100HP Electrical, Control Box Installation (700077KIAFJ11 and After)

ITEM

PART NO.

1 2

46839909 46847258

PART NO.

DESCRIPTION

46839914

PANEL, ELECTRICAL MOUNTING

46840368

CONTROLLER, DISPLAY/CONTROLLER

46840407

CONTACTOR, MAGNETIC

46840408

CONTACTOR, MAGNETIC

46840409

CONTACTOR, MAGNETIC

46838880

CONTACTOR, MAGNETIC

46840410

BREAKER, OVER CURRENT PROTECTION

46839251

BREAKER, OVER CURRENT PROTECTION

46840411

CIRCUIT BREAKER

46840411

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840374

CIRCUIT BREAKER

46840375

CIRCUIT BREAKER

46838884

CIRCUIT BREAKER

46838885

SWITCH ASSEMBLY, E-STOP

46838886

NOISE FILTER

46840376

SWITCH, POWER SUPPLY

46838887

SPARK KILLER

46838888

RELAY, PHASE MONITORING

46839377

TERMINAL BLOCK

46840377

TERMINAL BLOCK

46840378

TERMINAL BLOCK

46839378

TERMINAL BLOCK

46843190

TRANSFORMER

46838896

TRANSDUCER, PRESSURE

46838895

SENSOR, TEMPERATURE

46839379

GROUND BAR

100HP Electrical, Control Panel Assembly (700077KIAFJ11 and After)

PART NO.

DESCRIPTION

46847258

PANEL, ELECTRICAL MOUNTING

46840411

CIRCUIT BREAKER

46840373

CIRCUIT BREAKER

46840374

CIRCUIT BREAKER

46843188

CIRCUIT BREAKER

46843189

CIRCUIT BREAKER

46847259

CONTACTOR, MAGNETIC

46840409

CONTACTOR, MAGNETIC

46838880

CONTACTOR, MAGNETIC

46847260

BREAKER, OVER CURRENT PROTECTION

46839251

BREAKER, OVER CURRENT PROTECTION

46839379

GROUND BAR

46838885

SWITCH ASSEMBLY, E-STOP

46840368

CONTROLLER, DISPLAY/CONTROLLER

46838886

NOISE FILTER

46838896

TRANSDUCER, PRESSURE

46840376

SWITCH, POWER SUPPLY

46838887

SPARK KILLER

46838888

RELAY, PHASE MONITORING

46838895

SENSOR, TEMPERATURE

46839377

TERMINAL BLOCK

46839378

TERMINAL BLOCK

46840377

TERMINAL BLOCK

46840377

TERMINAL BLOCK

46843190

TRANSFORMER























































No comments:

Post a Comment
